Certified fan performance data for fans
of VS 225-VS 400 sizes
Unit Size Q (cfm) Ps (in. wg) BHP (hp)
VS-225
3450 RPM
1,047 0.004 0.251
944 0.661 0.277
841 1.290 0.328
737 0.195 0.363
633 2.446 0.374
522 2.868 0.381
422 3.056 0.353
314 3.162 0.300
158 3.220 0.234
0 3.423 0.158
VS-250
3450 RPM
1,447 0.015 0.421
1,300 1.087 0.525
1,162 2.000 0.645
1,013 2.892 0.721
868 3.536 0.747
720 3.883 0.708
594 4.065 0.646
426 4.200 0.537
283 4.258 0.442
0 4.619 0.250
VS-315
3450 RPM
3,124 0.011 1.850
2,824 1.280 2.027
2,514 2.788 2.244
2,196 4.281 2.490
1,887 5.376 2.563
1,558 6.086 2.485
1,247 6.391 2.306
930 6.566 2.059
529 6.714 1.714
0 7.275 0.945
VS-355
1750 RPM
2,344 0.001 0.395
2,119 0.469 0.466
1,882 0.978 0.516
1,636 1.462 0.565
1,396 1.834 0.585
1,167 2.021 0.561
937 2.093 0.524
689 2.141 0.454
457 2.186 0.382
0 2.300 0.226
VS-400
1750 RPM
3,212 0.003 0.739
2,898 0.601 0.838
2,577 1.269 0.956
2,245 1.815 1.034
1,926 2.310 1.079
1,620 2.585 1.051
1,281 2.709 0.959
957 2.770 0.844
512 2.794 0.690
0 2.921 0.432
Performance certied is for installation Type A, Free Inlet, Free Outlet. Power rating (BHP) does not include transmission losses.
Performance ratings do not include the effects of appurtances (accessories).
Efciency ratings are fan static and exclude bearing and/or Power Transmission Losses.
VTS America Inc. certies that the Model VS shown herein is licensed to bear the AMCA Seal. The ratings shown are based on tests and procedures
performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the requirements of the AMCA Certied Ratings Program.
NOTE 1:
NOTE 2:
NOTE 3
Certified fan performance data for fans
of VS 450-VS 630 sizes
Unit Size Q (cfm) Ps (in. wg) BHP (hp)
VS-450
1750 RPM
4,673 0.002 1.206
4,211 0.526 1.323
3,740 1.377 1.544
3,277 2.228 1.766
2,815 2.909 1.871
2,334 3.284 1.804
1,874 3.393 1.662
1,394 3.460 1.414
651 3.526 1.056
0 3.707 0.654
VS-500
1750 RPM
6386 0,000 1,756
6157 0,606 1,957
5613 1,638 2,480
5070 2,449 2,882
4527 3,071 3,083
3984 3,525 3,097
3441 3,842 2,962
2897 4,047 2,708
2354 4,163 2,386
0 4,464 1,032
VS-560
1750 RPM
9064 0,000 2,828
8240 1,566 4,062
7441 2,738 4,906
6643 3,633 5,416
5844 4,296 5,550
5045 4,757 5,362
4247 5,050 4,946
3448 5,223 4,383
2649 5,303 3,740
0 5,420 1,072
VS-630
1750 RPM
13061 0,000 4,651
11772 1,778 7,038
10594 3,352 8,646
9417 4,549 9,611
8240 5,412 9,853
7063 6,010 9,504
5886 6,391 8,713
4709 6,596 7,641
3649 6,684 6,568
0 6,877 2,560
Performance certied is for installation Type A, Free Inlet, Free Outlet. Power rating (BHP) does not include transmission losses.
Performance ratings do not include the effects of appurtances (accessories).
Efciency ratings are fan static and exclude bearing and/or Power Transmission Losses.
VTS America Inc. certies that the Model VS shown herein is licensed to bear the AMCA Seal. The ratings shown are based on tests and procedures
performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the requirements of the AMCA Certied Ratings Program.
NOTE 1:
NOTE 2:
NOTE 3
