Pos. Code Previous code Description Notes From: To:
0001 LA70010370 LAR70010370 GASKET [C]
0002 LA11207240 LAR11207240 LOWER HINGE KIT [C] M-V/061-101-102 2005
0003 LA62280038 LAR62280038 CURVE [C]
0004 LAR69180210 DRAIN CONTAINER [C] N/S071-101 2014
0005 LAR10201710 AIR FILTER [C] DRAIN M/210-12 D.86/44,5
0006 LA14402130 LAR14402130 HINGE [C]
0008 LA58003870 LAR58003870 COUNTER FLANGE [C]
0009 LA58004050 LAR58004050 NUT [C]
0010 LA58000360 LAR58000360 NUT [C]
0011 LAR65110330 DOUBLE SOLENOID VALVE 2 WAYS 230V 50/60HZ OUT
J.G. D.10
0012 LAR65110340 SOLENOID VALVE [C] 230V 50/60HZ 2 OUTLET JG
CONNECTION D. 10
0013 LA61630011 LAR61630011 ZINC CLAMP [C]
0014 LA61630031 LAR61630031 ZINC CLAMP [C]
0015 LA65280480 LAR65280480 FERRITE [C]
0016 LA65280490 TOROIDAL FERRITE [C] FT36
0017 LA65280240 LAR65280240 ELECTROMECHANICAL FILTER [C]
0018 LA69180250 LAR69180250 FILTER [C] CONTAINER DRAIN
0019 LA10400860 LAR10400860 FLANGE [C] MOTOR
0020 LA58003860 LAR58003860 FLANGE [C] GASKET
0021 LAR70010050 GASKET [C] 7,60X2,62
0022 LA70010030 LAR70010030 GASKET [C] 6,07X1,78
0023 LA70010210 LAR70010210 GASKET [C] 18,72X2,62
0024 LA70050150 LAR70050150 GASKET [C] BOILER CAP
0025 LA70020040 LAR70020040 GASKET [C]
0026 LA70010150 LAR70010150 GASKET [C] 55X35X3
0027 LAR70030180 GRAPHITE GASKETS KIT [C] 80x50,3x3 SET 5 PIECES
0028 LA65450211 INDUCTOR [C] 27 mH 8A
0029 LAR65140090 INVERTER [C] 0,8KW UL UL Version (USA-CAN)
and 110-120V
0029 LAR65140100 INVERTER 0,8 KW 4/1/2018
0029 LAR65141040 INVERTER [C] 0.8KW 3/30/2018
0030 LA62030113 LAR62030113 COUPLING [C] BRASS REDUCTION
0031 LA70060080 SILICONE COUPLING [C] D. 13X18X80
0032 LA70060040 LAR70060040 SILICONE COUPLING [C] D. INNER 51 D. EXTERIOR 59
0033 LAR75300020 PLATE [C] FAN D. 120
0034 LA75300050 LAR75300050 PLATE [C] FAN D. 270 N/S071 2014
12/13/2021 9:32:00 AM
This document is exclusive property of LAINOX ALI Group S.r.l. and should not be distributed, reproduced, into any other format without prior permission of LAINOX ALI Group S.r.l. -
Specifications subject to change without prior notice
Page 2 of 12
