Pos. Code Previous code Description Notes From: To:
0035 LAR65265100 MICROSWITCH [C] DOOR
0036 LA65220280 TERMINAL BLOCK [C]
0037 LA65160550 LAR65160550 SUPPORT [C] HEAT-GUARD 3RU1916-3AA01 UL Version (USA-CAN)
0037 LA65160620 LAR65160620 HEAT-GUARD [C] 1,4-2,0 UL Version (USA-CAN)
0037 LAR65040600 MOTOR [C] 220/240V 0,25KW ONE SPEED
0037 LAR65041300 MOTOR [C] 230V 50/60HZ 0,25KW ONE SPEED UL Version (USA-CAN)
0037 LAR65200400 FUSIBILE X MOT. KTK-R-6 600V 6A CL. CC UL Version (USA-CAN)
0037 LAR65210110 PORTAFUSIBILE BUSMANN BCC3X38 (2306338) UL Version (USA-CAN)
0038 LA69010260 LAR69010260 PRONG [C]
0038 LAR69010270 DOOR LATCH 2 STEP [C]
0040 LA63060160 LAR63060160 IGNITION PANEL [C]
0040 LA63060180 DASHBOARD [C] TS=5 TPS=1 UL UL Version (USA-CAN)
0041 LA58003140 LAR58003140 PIN [C] DEFLECTOR HOOK
0042 LAR58003110 PIN [C] DEFLECTOR CLAMPING
0043 LA58000370 LAR58000370 PIN [C] UPPER HINGE
0044 LA58002670 LAR58002670 LOWER PIN [C] HINGE SR 2005
0045 LA65210020 LAR65210020 FUSE CARRIER [C] 5X20
0046 LAR65240010 FAIRLEAD [C]
0046 SIR0101302 PRESSACAVO UL Version (USA-CAN)
0047 LAR63070050 WATER PRESSURE SWITCH [C] 500/350 mbar -1/8
0048 LA63070010 LAR63070010 PRESSURE SWITCH [C]
0049 LAR65095000 RELEASE MOTOR [C] COMPLETE - 1 CAM
0050 LAR62090508 STRAIGHT CONNECTOR [C] END SIDE PIPE 10X1/4
0051 LA62090528 LAR62090528 CURVED CONNECTOR [C] 10X10
0052 LA62090478 LAR62090478 INTERMEDIATE CURVED CONNECTOR [C] D. 10
0053 LA62090633 LAR62090633 CURVED CONNECTOR [C] 10/10
0054 LA62090918 LAR62090918 INTERMEDIATE CURVED CONNECTOR D.10
0055 LA65110510 LAR65110510 MASS FLOW RED REGULATOR [C] 15L/H
0056 LA58004010 LAR58004010 WASHER [C] D. 30/12,5
0057 LAR69180120 BOX [C] DRAIN PIPE G/MV T06-T10-T21
0058 LAR65320220 PROBE [C] K L. 1,5M
0059 LA69180340 DOOR [C] REMOVABLE TANKS
0060 LA69150100 LAR69150100 CAP [C]
0061 LAR58006690 CAP [C] SERIE 2014
0062 LA65140900 CONTACTOR [C]
0063 LA65070350 LAR65070350 THERMOSTAT [C] 360°C-25K
12/13/2021 9:32:00 AM
This document is exclusive property of LAINOX ALI Group S.r.l. and should not be distributed, reproduced, into any other format without prior permission of LAINOX ALI Group S.r.l. -
Specifications subject to change without prior notice
Page 3 of 12
