Apach LGI071T Монтажная схема онлайн [4/12] 677624

Pos. Code Previous code Description Notes From: To:

0063 LA65070370 THERMOSTAT [C] 360Â°C UL Version (USA-CAN)

0064 LA65180420 TRANSFORMER [C] 20VA 0-220-240/12V 10/18/2019

0064 LA65187260 BALLAST [C] LED APV-12-12 LED 10/21/2019

0065 LA65180430 TRANSFORMER [C] 40VA 0-220-240/12V

0065 LA65187110 TRANSFORMER [C] 40VA 2.5/12/24V UL Version (USA-CAN)

0066 LA80150000 LIGHT BLUE POLYETHYL PIPE D. 10X7MM

0067 LA80150060 LAR80150060 PIPE [C] PEX-B D. 10MM L.100M

0068 LA58000740 NOZZLE [C] D. 0,80 Su tubo scarico / On

drain pipe

0068 LA58006160 NOZZLE [C] D. 0,80 Su scatola

condensazione / On

quenching box

0069 LA65060050 LAR65060050 FAN [R] D. 120 4715MS 23T

0074 LAR61250312 LAR61260152 SCREW [C] M4X10 UNI 6107

12/13/2021 9:32:00 AM

This document is exclusive property of LAINOX ALI Group S.r.l. and should not be distributed, reproduced, into any other format without prior permission of LAINOX ALI Group S.r.l. -

Specifications subject to change without prior notice

Page 4 of 12
