Монтажная схема Страница: 6

Apach ASH600/1500 [6/7] Mod gpb tav 3

ED. 2013

N° 500 600

DENOMINAZIONE DENOMINATION

DENOMINATION BENENNUNG DENOMINACIÓN

1 20060

SPINA 6 X 30 FERMO MANIGLIA PIN FICHE STIFT PASADOR

2 20011 FERMO MANIGLIA

HANDLE LOCK ARRÊT POIGNÉE HANDGRIFFHALTEVORRICHTUNG FIJADOR MANIJA

3 20020 MOLLA PER FM SPRING RESSORT FEDER MUELLE

4 20050 SPINA 6 X 40 PER MANIGLIA PIN FICHE STIFT PASADOR

5 20016 MANIGLIA HANDLE POIGNEE GRIFF MANIJA

6 30026 SETTORE DENTATO TOOTHED SECTOR SECTEUR DENTELÉ GEZÄHNTER BEREICH SECTOR DENTADO

7 20004 SETTORE MOBILE MOBILE SECTOR SECTEUR MOBILE BEWEGLICHER BEREICH SECTOR MOVIL

8 20009 VOLANTINO PER FERMO SM

HANDLE PETITE POIGNÉE GRIFF POMO

9 20015 FERMO SETTORE MOBILE MOBILE SECTOR LOCK ARRÊT SECTEUR MOBILE HALTEVORRICHTUNG BEWEG-

LICHEN BEREICHS

PARO SECTOR MOVIL

10 20038 INTERRUTTORE GENERALE GENERAL SWITCH INTERRUPTEUR GÉNÉRAL HAUPTSHALTER INTERRUPTOR GENERAL

11 30037 SELETTORE 1-2 V SPEED SELECTOR SELECTEUR WÄHLSCHALTER SELECTOR

12 35B03 COPERCHIO LATO MANIGLIA COVER COUVERCLE ECKEL TAPA

13 30035 PULSANTE MARCIA PUSH-BOTTOM START BOUTON START START DRUCKKNOPF PULSADOR START

14 30036 PULSANTE EMERGENZA PUSH-BOTTOM BOUTON DRUCKKNOPF PULSADOR

15 30034 MANIPOLATORE /JOYSTICK JOYSTICK JOYSTICK JOYSTICK JOYSTICK

16 30009 PANNELLO COMANDI UPPER CONTROL CASE PANNEAU COMMANDES SUP. PANEL SCHALTER PANEL MANDOS

17 35B02 SPALLA POSTERIORE WEB EPOULEMENT SCHULTER BRAZO

18 2B532 GANCIO FERMA PIANO LOCK WORKING PLANE CROCHET ARRÊT PLAN EBENEHALTEHACKEN GANCHO BLOQUEO

19 35B01 SPALLA ANTERIORE WEB EPOULEMENT SCHULTER BRAZO

20 2B503 36027 VASCHETTA PORTA FARINA

FLOUR HOLDING CUP BASSIN PORTE FARINE MEHLKASTEN RECIPIENTE PORTA-HARINA

21 2B5X19 26046 MATTARELLO ROLLING PIN ROULEAU NUDELHOLZ RODILLO-MADERA

22 2B5X31 36012 RIPARO SX GUARD PROTECTION SCHUTZ PROTECIÓN

23 2B5X17 36011 RIPARO DX GUARD PROTECTION SCHUTZ PROTECIÓN

24 20003 PORTA MATTARELLO ROLLING PIN HOLDER PORTE ROULEAU NUDELHOLZHALTER PORTA RODILLO

25 15022 SCHEDA ELETTRICA 3PH ELECTRIC PLATE FICHE ELECTRIQUE KARTE CUADRO ELECTRICO

25 15031 SCHEDA ELETTRICA 1PH ELECTRIC PLATE FICHE ELECTRIQUE KARTE CUADRO ELECTRICO

26 35006 36023 TIRANTE QUADRO 14 X 14 AXE CARRE 14 X 14 SQUARED ASLE 14 X 14 SCHULTERANKER 14X 14 TENSOR BRAZO 14X 14

27 23552 36007 PIANO CORTO TABLE COURTE SMALL WORKING PLANE EBENE PLANO

27 23551 36008 PIANO LUNGO TABLE LONGUE BIG WORKING PLANE EBENE PLANO

28 35002 36009 PROLUNGA EXTENSION RALLONGE VERLÄNGERUNGSSTÜCK PROLUNGACIONES

29 30024 STAFFA PER PROLUNGA BRACKET FIXATION TRÄGER SOPORTE

30 30040 POMELLO PER PROLUNGA KNOB POMMEAU GRIFFE POMO

31 35B06 RIPARO INFERIORE/MOTORE PROTECTION INFERIEUR BOTTOM GUARD SCHUTZ PROTECCION

32 2B5X55 RIPARO RULLO RINVIO GUARD PROTECTION SCHUTZ PROTECCIÓN

33 2B5X20 ANGOLARE RULLO RINVIO SUPPORT ANGULAIRE WINKELEISEN ANGULAR

MOD. GPB TAV. 3

Apach ASH600/1500 [6/7] Mod gpb tav 3
