TaglierinaSlicer
ELENCO PARTI DI RICAMBIO
SPARE PARTS LIST
ALLEGATO 1
C42/52, C42S/52S, G42
03/10/2014 Rev. C
7/7
POS.
CODE
420
CODE
520
DESCRIZIONE
DESCRIPTION
1
Telaio portalame (varie
misure)
Blades’s frame
5 D00617 D00617 Leva tiramolla sinistro
Left spring level
6 D00616 D00616 Leva tiramolla destro
Right spring level
7 P00488 P00488 Lama inox con perni
Stainless steel blade with
pins
8
Premipane (varie misure)
Bread presser
9 D02800 D02800 Molla con occhiello
Spring with eyebolt
10
Spingipane (varie misure)
Bread pusher
11 D00632 D00632 Guida per spingipane
Bread Pusher guide
12
Scivolo posteriore (varie
misure)
Rear Slide
13
Spingipane (vari passi)
Bread pusher
14 D02797 D02798 Feltro per oliatura SM42
Oiling Felt SM42
15 D01612 D01622 Lamiera premi feltro
Oil felt presser sheet
16 D01613 D01623 Serbatoio olio
Oil tank
17 C00599 C00599 Tappo olio
Oil cap
20 D03117 D03117 Pattino spingipane
Slide for bread pusher
Fino a matr. 18800 su modelli C42 e C52
Fino a matr. 18815 su modelli G e G42-C
Fino a matr. 19020 su modelli C42S e C52S
POS.
CODE
420
CODE
520
DESCRIZIONE
DESCRIPTION
2 D01431 D01431 Biella
Connecting rod
3 D00614 D00614
Perno superiore telaio
portalame
Upper pin blade’s frame
4 C00046 C00046 Vite rettificata
Rectified screw
19 G00553 G00553
Kit supporti elastici per C e
G
Rubber joints kit for C and
G model
19 G00554 G00554 Kit supporti elastici per CS
Rubber joints kit for CS
model
Da matr. 18842 su modelli C42 e C52
Da matr. 18855 su modelli G e G42-C
Da matr. 19029 su modelli C42S e C52S
POS.
CODE
420
CODE
520
DESCRIZIONE
DESCRIPTION
18 D03046 D03046 Supporto elastico
Rubber joint
