Kadzama струнная резка [7/14] Before start
![Kadzama струнная резка [7/14] Before start](/views2/1898095/page7/bg7.png)
1 — Frames
2 — Bedplate
3 — Removable plate
———
1 — Рамы
2 — Станина
3 — Лист-съемник
6 — Before start
Подготовка к работе
6.1. Remove the packaging.
6.2.1. In the case of a set without a carriage:
— Set guitar candy slicer on a flat hard surface, providing
easy access for the frame movement.
6.2.2. In the case of a set with a carriage:
— Assemble the carriage as shown on the picture:
7
