Model 16U748

(Maximum Working Pressure: 5000 psi, 34.5 MPa, 345bar)

Model 16U749

(Maximum Working Pressure: 10000 psi, 68.9 MPa, 689 bar)

Related Manuals:

Pressure Relief Procedure

1. Set pump valve OFF. Turn engine OFF.

2. Turn pressure to lowest setting. Trigger gun into pail to relieve pressure.

3. Open prime valve (vertical).

If you suspect that the spray tip or hose is completely clogged, or that pressure has not been fully relieved after following the

steps above, VERY SLOWLY, loosen tip guard retaining nut or hose end coupling to relieve pressure gradually, then loosen com-

pletely. Then clean tip and hose.

Series Maximum Working Pressure Gauge Kit

GH2570ES Bare 2500 psi (17.2 MPa, 172 bar) 16U748

GH733ES Bare 4000 psi (27.6 MPa, 276 bar) 16U748

GH5040ES Bare 5000 psi (34.5 MPa, 345 bar) 16U749

GH933ES Bare 7250 psi (50.0 MPa, 500 bar) 16U749

GH933 Bare 7250 psi (50.0 MPa, 500 bar) 16U749

IMPORTANT SAFETY INSTRUCTIONS

Read all warnings and instructions in sprayer

manual. Save these instructions.

332156

332157

332158

System pressure must be manually relieved to prevent it from starting or spraying accidentally. Fluid under high pressure can be

injected into the skin and cause serious injury. To reduce risk of injury from injection, follow this procedure whenever you are instructed

to relieve pressure, stop spraying, service equipment or install or clean spray tip. Read warnings, in operation manual.

332232A

Instructions

Gauge Kit for GH2570ES, 5040ES,

733ES, 933, and 933ES Big Rig Sprayers
