Rekam VisaVis L120 [13/19] Installing replacing the battery

24 25

12. OK – Press to conrm. Play/pause: In the playing mode, press this

button, for pause / resume .

13. ZOOM – In the pause state of single picture, press ZOOM to mag‑

nify picture display size.

14. / 15. VOL +/- – Turn up/down thevolume.

16. ROTATE – In the pause state of single picture, press this button to

revolve the picture 90°in clockwise direction each time.

17.

– Move back to previous music orvideo le.

18. – Move forward to next music orvideo le.

1.2BACK OF FRAME

1. Power

2. UP

3. VOL +/RIGHT

4. DOWN

5. Play/Pause/OK

6. VOL ‑/ LEFT

7. MENU/EXIT

1. SD/MMC/MS/SDHC CARD

2. Earphone jack

3. USB 2.0

4. Mini USB

5. DC IN

2. iNSTALLiNG & REPLACiNG ThE BATTERy

Place the remote control face down, press down on the ridged area

of the battery cover and pull towards you to remove the tray. Place

one CR2025lithium button‑cell battery on the tray with the positive “+”

side facing you. Reinsert the tray.

3. GETTiNG STARTEd

3.1 Put the digital photo frame withinstalling bracket on a at posi‑

tion stability, then plug one end of the AC adapterinto a standard

100—240V AC electrical outlet and the other endinto the DCIN

slot on the frame.

Note: The bracketinstalling and standing method refer to «StandIn‑

struction».

3.2 Remove the protective lm covering on the LCD.

3.3 Remove the plastic battery insulator from the battery compart‑

ment and make sure the remote control has a batteryinside. Please

refer to “Installing & Replacing Battery” if you need a new battery.

3.4 Press the Power button on the Remote Control or the power key

on the unit
