Setup
20 312065V
Grounding
• Reactor: is grounded through power cord. See
Connect electrical cord, page 21.
• Spray gun: connect whip hose ground wire to FTS,
see Install Fluid Temperature Sensor (FTS), page
22. Do not disconnect wire or spray without whip
hose.
• Fluid supply containers: follow your local code.
• Object being sprayed: follow your local code.
• Solvent pails used when flushing: follow your
local code. Use only metal pails, which are
conductive, placed on a grounded surface. Do not
place pail on a nonconductive surface, such as
paper or cardboard, which interrupts grounding
continuity
• To maintain grounding continuity when flushing
or relieving pressure, hold a metal part of spray
gun firmly to the side of a grounded metal pail, then
trigger gun.
Electrical requirements
Table 1: Electrical Requirements
(kW/Full Load Amps)
E SERIES
Part Model
Nominal
Voltage
Range
(phase)
Full
Load
Peak
Amps*
System
Watts**
259025 E-20 200-240 V (1) 48 10,200
249030 E-20 350-415 V (3) 24 10,200
259034 E-20 200-240 V (3) 32 10,200
259026 E-30 200-240 V (1) 78 17,900
259031 E-30 350-415 V (3) 34 17,900
259035 E-30 200-240 V (3) 50 17,900
259057 E-30† 200-240 V (1) 100 23,000
259058 E-30† 200-240 V (3) 62 23,000
259059 E-30† 350-415 V (3) 35 23,000
E-XP SERIES
259024 E-XP1 200-240 V (1) 69 15,800
259029 E-XP1 350-415 V (3) 24 15,800
259033 E-XP1 200-240 V (3) 43 15,800
259028 E-XP2 200-240 V (1) 100 23,000
259032 E-XP2 350-415 V (3) 35 23,000
259036 E-XP2 200-240 V (3) 62 23,000
* Full load amps with all devices operating at
maximum capabilities. Fuse requirements at various
flow rates and mix chamber sizes may be less.
** E-20 and E-XP1 with 210 ft (64.1 m) hose; E-30 and
E-XP2 with 310 ft (94.6 m) hose.
† E-30 with 15.3 kW of heat.
Installing this equipment requires access to parts
which may cause electric shock or other serious injury
if work is not performed properly. Have a qualified
electrician connect power and ground, see Connect
electrical cord, page 21. Be sure your installation
complies with all local codes and regulations.
