3A7683G
EN
Instructions
Reactor
®
3 Heated Hose
For use with Reactor 3 proportioners. For professional use only. Not approved for use in
explosive atmospheres or hazardous (classified) locations.
130 psi (0.9 MPa, 9 bar) Maximum Air Working Pressure
See page 3 for model information, including approvals. See
Technical Specifications on page 25 for Maximum Fluid
Working Pressure and Maximum Hose Operating
Temperature.
Important Safety Instructions
Read all warnings and instructions in this
manual and in your Rector 3 manual
before using the equipment. Save these
instructions.
