6
7
NEW ISO LUBE PUMP
•
Active ISO Lube system with peristaltic pump
•
Automatic timed circulation improves TSL Life
•
Reduced maintenance (No check valves)
•
New larger easy-to-change ISO lube bottle
NEW INLET FILTERS
•
New easy-to-maintain design
•
2X larger filter area
•
Separate temperature and pressure sensors
for more accurate temperature readings
REACTOR CONNECT
•
Real-time dashboard and reports
via cellular connectivity
•
Improved cellular antenna
•
New GPS antenna
•
GPS location available in Reactor Connect
NEW TOUCHSCREEN
ADVANCED DISPLAY MODULE (ADM)
•
Large new touchscreen interface
•
Intuitive operation and navigation
•
All spray operations from one screen
OVAL GEAR FLOW METERS (under shroud)
•
Verifies fluid ratio
•
Provides real-time ratio data:
displayed on the ADM and Reactor Connect
•
Accurate for a wide range of fluid viscosities
NEW ADVANCED ELECTRIC DESIGN
•
Brushless motor for improved pressure/flow performance
•
New temperature control boards for independent hose heat
•
Voltage jumpers for easy changing between voltages
•
Robust UL listed electrical hose connectors are
color coded and keyed for error proof assembly
•
New Reactor 3 exclusive: connect with Tier 4 engines
for ADM engine diagnostic
REDUCED SIZE
•
Reduced footprint provides additional room
in your rig
•
Compact design protects the flow meters and
hose connections from being damaged in your rig
NEW INDEPENDENT HOSE CONTROL
•
Control A and B materials to different
temperatures for improved pressure balancing
•
Optimizes yield
NEW FLUID MANIFOLD
•
Redesigned with side-mounted fluid valves
for easier turning and improved control
REACTOR 3 ELECTRIC
PROPORTIONER
The ONLY Fully-Connected
System From Drum to Gun
Upgrade your rig with a powerful NEW Reactor 3
proportioner, built with advanced capabilities for
spray foam and polyurea applications. Reactor 3 is
designed to communicate with the entire system
to simplify the operator's job, optimize spray
parameters and maximize productivity.
NEW ADVANCED
SOFTWARE FEATURES
•
Katalyst: Reactor Intelligence from drum-to-gun.
System communication and control that improves
performance, ratio and yield.
•
Auto Pressure Balance: Reactor automatically adjusts
temperatures to optimize fluid pressures and maximize yield
•
Supply Pump Shutdown: Automatically shuts down
when you run out of material. Prevents air from entering
the system that can cause off-ratio issues.
(Requires Core E1 pumps)
•
Smart Supply: Automatically monitors and adjusts
fluid inlet pressures to compensate for high viscosity
(e.g., cold) materials to keep you spraying on ratio
(Requires Elite Reactor paired with Core E1 pumps)
•
Resistance Control Mode: Accurately monitors and controls
hose temperatures without the hassles of fluid sensors and
RTD cables
•
Power Management: Select desired heater wattage for
reduced power consumption
•
Cellular Software Updates: Automatically stay
up to date with the latest Reactor software
(Requires Reactor Connect)
•
Jog Countdown Timer: Input a cycle count value and have
the machine run and shut off after that exact value to assist
if precisely flushing the system
* Picture shown represents
an Elite model.
* Some features and software are only available
on Pro and/or Elite models.
