CORE E1 ELECTRIC TRANSFER PUMPS
Powerful, Quiet, Smart
Get in the flow with Graco's revolutionary NEW Core electric transfer pumps; designed to optimize material supply
and minimize downtime. Quieter and less expensive to operate than traditional pneumatic pumps, the new
electric pumps can communicate with the Reactor 3 to give you a fully-connected system.
NEW XCELERATOR HEATED HOSES
Faster to Heat, Lighter Weight, Improved Flexibility
Graco’s new Xcelerator heated hoses provide more options and control than ever. All Xcelerator hoses are designed to provide
full independent A and B temperature control. This provides more precise pressure balancing and improved
material yield. New robust construction provides longer life and reduced maintenance.
DESIGNED FOR SPEED AND RELIABILITY
•
Fully-independent A and B temperature control
•
Internally heated and externally heated options
•
Internally heated hoses available in both
50 ft and 100 ft lengths: Minimizes fluid
and electrical connections
•
Optimized for Resistance Control Mode:
Reduces maintenance and issues
with no cables or sensors required
GRACO'S NEW INTERNAL HEATED HOSE HAS THE SMALLEST,
LIGHTEST WEIGHT CONNECTIONS IN THE INDUSTRY
The robust, compact design allows the heating element to enter/exit the
fluid stream at each hose joint without adding significant size or weight.
HOSE CONNECTIONS THAT ARE LIGHTWEIGHT AND ROBUST
Graco's new electrical connectors are designed with the user in mind
With our exclusive ProConnect technology,
you can quickly disconnect the motor from
the pump lower and easily transfer the pump
from drum to drum… even in low ceiling
height rigs. Paying for taller rigs or having
to tip the drum to remove the pump is no
longer necessary.
TIP: Have an extra pump lower installed on
your rig to make changing drums even faster
and cleaner.
CONNECTIONS MADE EASY!
Connecting your motor to the lower just got as easy as 1, 2, 3.
1. Loosen T-handle 2. Open Pump Clamp 3. Slide Electric Motor
to Remove
NEW SMART SUPPLY
The software automatically monitors and adjusts Reactor 3 proportioner
inlet pressures to optimize material feed and on-ratio performance.
Maintains inlet pressure between 80 – 200 psi — boosting power
to the transfer pump’s electric motors when needed. Achieve Smart
Supply when using Core E1 pumps with a Reactor 3 Elite model.
NEW SUPPLY PUMP SHUTDOWN
Senses when a drum is empty and automatically shuts down the
transfer pumps and Reactor 3 proportioner before damage occurs,
including air entering the system and that can compromise ratio.
That’s equivalent to reducing
the sound in your rig from
being as loud as a motorcycle
to that of a car.
XCELERATOR HEATED HOSESCORE E1 TRANSFER PUMPS
Heating Wire
•
Heating wire is located in hose ID for direct
material contact and quick heating
Wire Seal Nut/Ferrule/O-ring/Bushing
•
These components allow the heating wire to
transition out of fluid and provide a proper seal
Crimp Connector
•
Connects the heating wire to the multi-strand wire
that allows the hose power to connect between hose joints
Pin and Socket Connectors
•
Male/Female connectors provide a strong, reliable electric connection
Gasket and O-Ring Seal
•
Provides moisture-proof electrical connection
Keyed Feature
•
Unique keys on A and B connectors prevent incorrect connections
1
1
1
2
2
1
3
2
2
3
3
3
Xcelerator
Than Pneumatic Pumps
UP TO
QUIETER
6X
INTERNAL
HEATED HOSE
MORE
FLEXIBLE
40
%
SMALLER
DIAMETER
35
%
FASTER
HEAT-UP TIME
40
%
PATENT PENDING
PATENT PENDING
