High-production Systems
What a hydraulic system can do for you:
• Dependability – robust, durable, longest life spray system
• Reduced downtime – allows for longer time in-between required maintenance
• Increased daily productivity – capable of extremely high duty cycles
Reactor 2 Hydraulic Series
Graco’s line of hydraulic Reactors brings increased yield and performance
to high-output spraying. Ideal for in-plant OEMs or applicators that
spray high volume. Reactor 2 models are available in an
H-30, H-40, H-50, H-XP2 and H-XP3.
Advanced Controls
• Easy to operate Advanced Display Module interface
• Reactor Connect hardware included with all models
Ergonomic Set-up
• Electronics are above the pumps –
comfortable height for easier service
Voltage Jumpers
• Available on H-30 and H-XP2 (inside electronics cabinet)
allows for one model to be wired to different voltages
Horizontal Pump Line
• Slower cycle rate
Easy Troubleshooting Diagnosis
• Troubleshooting Y-strainers for analog
temperature and pressure gauges
• Inlet pressure and temperature is
displayed and recorded on ADM
Oval Gear Flow Meters
• Simple and robust design
• Ideally suited for high flow rate measurements
• Accuracy of
+
/
–
1%
• Included on elite models
• Kits available to add to all Reactor 2 models
*Elite Models
• Inlet pressure and temperature sensors
• Xtreme-Wrap
™
Scuff Guard on heated hoses
when ordered as a package
• Ratio Assurance System
Resistance Control Mode
• Provides full hose temperature control without
RTD cables or Fluid Temperature Sensor
• Increased material yield and productivity
• Less downtime and repair costs
