Asko HPS 5323 S [4/48] Installation and use of a pedestal drawer

The pedestal drawer may only be used with a washing machine and a dryer by the manufacturer Asko Appliances.

Press on the pedestal drawer to open it.

Use both hands to pull out the pedestal drawer towards

you. Then, push the plastic levers located on the drawer

guides under the drawer on each side towards the middle in

order to release the stop preventing the drawer from being

pulled out completely.

Pull out the entire pedestal drawer.

Pull out the shelf in an upward arc.

Tilt the washing machine or dryer to either side, and use

a wrench (22 mm) to remove the metal feet.

5.1

Attaching the spacers to the washing machine.

First, screw the supplied nuts onto the spacer. Then, use

an open spanner (22 mm) to attach the spacers to the spot

where the metal feet were previously attached.

5.2

Attaching the spacers to the dryer.

Use an open spanner (22 mm) to attach the spacers to

where the metal feet were previously attached.

Attach the rubber caps onto the spacers in order to protect

your ﬂ oor during installation.

Tilt the machine to the other side and repeat steps 4 and 5.

The pedestal drawer is intended solely for installation under an appliance. The drawer can only support the weight of

one appliance. If a pedestal drawer is installed under a washing machine, do not install a dryer onto the washing machine,

or vice versa.

INSTALLATION AND USE OF A PEDESTAL DRAWER
