1
Update
CipherLab Barcode Scanners provide convenient and versatile solutions to meet your
business needs. The tethered handheld scanners are designed to help accelerate
productivity while lowering the total cost of ownership. Intensive data collection jobs are
made easier with fast, accurate barcode scanning in retail, industrial, manufacturing, and
enterprise environments.
Owing to the compact design, extremely low power consumption, and powerful decoding
capability, CipherLab Barcode Scanners are the best choice for the following applications
–
Receiving in Retail
Product labeling & Tracking
Shelf Product Replenishment
Mobile Point of Sale (POS)
Mobile Inventory Management
Order Picking & Staging
Work-In-Process Tracking
Material Flow Control
Transportation & Distribution
Warehousing
Asset Management
This manual contains information on operating the scanner and using its features. We
recommend you to keep one copy of the manual at hand for quick reference or
maintenance purposes. To avoid any improper disposal or operation, please read the
manual thoroughly before use.
Thank you for choosing CipherLab products!
INTRODUCTION
