Registration

The model and serial number are found on the rear of this unit. This number is unique to this unit and not

available to others. You should record requested information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Electrical Connections (In the UK Only)

The wires in this mains lead are coloured in accordance with the following code:

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured

markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is

marked with the letter E or by the earth symbol( ) or coloured Green or Green and Yellow.

The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or

coloured Black.

The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or

coloured Red.

If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362 fuse.

Blue(Neutral)

Fuse

Cord grip

Brown(Live)

Green and Yellow(Earth)

GREEN AND YELLOW:EARTH

BLUE:NEUTRAL

BROWN:LIVE

This appliance must be earthed

Important
