69
Additional Information
Specifications
CD/DVD player
Laser Semiconductor laser
Signal format system
PAL /(NTSC)
Audio characteristics
Frequency r esponse
DVD (PCM 96 kHz): 2 Hz to 44 kHz
(±0.5 dB)*
DVD (PCM 48 kHz): 2 Hz to 22 kHz
(±0.5 dB)
CD: 2 Hz to 20 kHz (±0.5 dB)
Signal-to-noise ratio
More than 110 dB (AUDIO OUT connector
only)
Harmonic distortion
Less than 0.0025%
Dynamic range
More than 100 dB (DVD)
More than 98 dB (CD)
W ow and flutter
Less than detected value
(±0.001% W PEAK)
Outputs and inputs
AUDIO OUT
DIGITAL OUT
(OPTICAL)
DIGITAL OUT
(COAXIAL)
VIDEO OUT
(1, 2)
S VIDEO OUT
(1, 2)
COMPONENT
VIDEO OUT
(Y, CB/B-Y,
CR/R-Y)
PHONES
5.1 OUTPUT
General
Power r equir ements
220 - 240V AC, 50/60 Hz
Power consumption
22 W
Dimensions (appr ox.)
430 × 98 × 305 mm (w/h/d)
incl. projecting parts
Mass (appr ox.)
4.0 kg
Operating temperatur e
5 ˚C to 35 ˚C
Operating humidity
5% to 90%
Supplied accessories
See page 7.
* The signals from AUDIO OUT connector and 5.1 ch L,R connectors
are measured. When you play the PCM sound tracks with 96 kHz
sampling frequency, the output signals from the DIGITAL OUT
(OPTICAL, COAXIAL) are converted to 48 kHz (sampling
frequency).
Design and specifications are subject to change without notice.
Jack
type
Phono
jacks
Optical
output
connector
Phono
jack
Phono
jacks
4-pin
mini DIN
Phono
jacks
Phone
jack
Phono
jacks
Output
level
2 Vrms
(at 50 kilohms)
–18 dBm
0.5 Vp-p
1.0 Vp-p
Y: 1.0 Vp-p
C: 0.3 Vp-p
(PAL)
0.286 Vp-p
(NTSC)
Y: 1.0 Vp-p
CB/B-Y,
CR/R-Y:
0.7 Vp-p
12 mW
2 Vrms
(at 50 kilohms)
Load impedance
Over 10 kilohms
Wave length: 660 nm
75 ohms terminated
75 ohms,
sync negative
75 ohms,
sync negative
75 ohms terminated
75 ohms,
sync negative
75 ohms
32 ohms
Over 10 kilohms
