Sony TRINITRON KV-AZ212M91 [6/48] Setting up your tv initial setup continued
![Sony TRINITRON KV-AZ212M91 [6/48] Setting up your tv initial setup continued](/views2/1091128/page6/bg6.png)
Sony KV-AZ212M91 Group B25 (GB (dummy))_2-687-422-E2 (1)
d) If you wish to edit the channels, press
to change to edit mode.
Press b until the mode that you wish to edit
is highlighted: Label, Skip,
(block symbol).
Then press
.
1) To label, press V or v to select the
alphanumeric characters for the label.
Then press
.
2) To skip the program number, press V or v to
select “On”. Then press
.
You can skip this program number when
using PROG +/–.
3) To block unwanted program number,
press V or v to select
. Then press .
e) Repeat step b) to d) if you wish to change other
channels.
Press WEGA GATE to go to the next menu.
4
Press B or b to adjust the bars on the top
and bottom of the menu if they are
slanted, then press
.
If no adjustment is necessary, then press
.
5
To prevent this “Initial Setup” menu from
appearing again when you turn on the TV
by pressing !, press V or v to select “No”,
then press
.
To allow this menu to appear again, select
“Yes”, then press
.
Tip
•You can immediately go to the end of the ”Initial Setup” menu by pressing WEGA GATE.
End
Select
Confirm
Picture Rotation
Select
Confirm
Display this menu next time?
No
Yes
Initial Setup
Exit
Select
Confirm
Program Sorting/Edit
Edit mode
Label Skip
PROG
01
04
03
02
Off
Off
Off
Off
Setting up your TV (“Initial Setup”) (continued)
Exit
Select
Confirm
Program Sorting/Edit
Edit mode
Label Skip
PROG
01
04
03
02
Off
Off
Off
Off
Exit
Select
Confirm
Program Sorting/Edit
Edit mode
Label Skip
PROG
01
04
03
02
Off
Off
Off
Off
01GB02WAR-SOEMRus.p65 5/15/07, 2:05 PM6
