To Reverse the Doors

Precaution

How to Reverse the Door

To separate the door handle of the left side, separate the

door cap and unscrew the screw in counterclockwise

direction.Separate the door handle of the freezer in the

same order. (You do not need to follow the above procedure

for the hidden h

andle.)

2.After unscrewing the screw of the right hinge cover on

the top, separate the right hinge cover to separate the

connecting cable .Separate the bolt fixating the upper

right hinge ,and carefully separate the refrigerator door .

3.After separating the upper left cap of the separated

refrigerator door , carefully take off the top cap and

pull the cable to connect to the hole on the left side.Set

the separated top cap at the regular position and set the

cap on the cable hole on the right side.Loosen the screw

under the cold room door , move it to the left of the

stopper , and then connect

it.

4.Press and separate the cap connected to the cover front

using the (+) driver, and unscrew the screws to

move the cable to the left to set it. After setti

ng the

separated cover front on the regular position, scr

ew the

screws and cover them with the cap in

cluded

with the owner’s m

anual.

1716

Your fridge-freezer is designed with reversible doors,so that they may open from either

the left or right hand side to suit your kitchen design.

Before reversing the door, first of all,you should take out food and accessories like

shelves or trays which are not fixed in the fridge-freezer.

Use Torque Wrench or Spanner to fix or remove the bolt.

Do not lay the fridge-freezer down.This will cause problems.

Be careful not to drop the doors in disassembling or assenbling
