COMPRAG Screw air compressor A-Series

5.5

Replacing air lter

The air lter (1) is attached to the com-

pressor’s intake valve.

In order to replace it, open the front side

panel, loosen the clamp (2) securing the

lter. Remove the contaminated lter, and

detach the clamp from it.

Set the new lter in its place and t into

place with the clamp.

Fig. 5.5 Air lter replacing

5.6

Changing drive belt

Fig. 5.6 Changing drive belt

Open the front and right side panel, loosen the 4 screws (3) securing the bracket of the air

end by turning them 2 revolutions. Loosen the 2 bolts of the support (2) and the 2 corre-

sponding nuts (1) on the tensioner using a wrench. Remove the old belts from the pulleys

and install the new belts. After installing the new belt, tighten the belt with the appropriate

tensile force (see section 5.3 Checking Drive Belt). Tighten the 2 bolts of the support (2)

1 3
