Comprag ACE-3 [10/56] Description of mechanism

CONTRACOR

Version 2.2

ENGLISH

1. Heat exchanger

2. Fan

3. Motor

4. Cyclone separator

5. Air distributor

6. Air preparation unit (ACP only)

7. Inlet port of compressed air

8. Drain valve

9. Motor starter (ACE only)

10. Power cable (ACE only)

11. Namenplate

12. Transport handle

13. Wheel

14. Pressure regulator

15. Manometer

16. Filter

17. Oiler

2.6 Description of mechanism

For ACE model:

Compressed air from the compressor enters the radiator (3) via the air line, where it is

cooled by the fan (2) with electric drive, which is switched on via the motor starter (8). The

cooled air from the radiator is fed into the cyclone separator (4), where the air is dried by

removal of moisture. From the cyclone separator, the compressed air enters the distributing

header (5), from where it can be supplied to 3 consumers simultaneously.

For ACP model:

Compressed air from the compressor enters the radiator (3) via the air line, where it is

cooled by the fan (2) with pneumatic drive (1). The fan speed is set using a pressure

regulator on the air-preparation unit. The cooled air from the radiator is fed into the cyclone

separator (4), where the air is dried by removal of moisture. From the cyclone separator,

the compressed air enters the distributing header (5), from where it can be supplied to 3

consumers simultaneously, as well as to the pneumatic motor (1) via the air-preparation

unit (6). In the air-preparation unit, oil is added to reduce wear of the pneumatic motor’s

moving components and additional condensate is removed.
