MEG Z590I UNIFY

НА ТЕМНОЙ СТОРОНЕ

SPECIFICATIONS

Model Name MEG Z590I UNIFY

CPU Support

Supports 10th Gen Intel

Core™ Processors, 11th Gen Intel

Core™ Processors, Pentium

Gold and Celeron

Processors

CPU Socket LGA 1200

Chipset

Intel

Z590 Chipset

Graphics

Interface

1x PCIe 4.0 x16 slot

Display Interface Support 4K@60Hz as speciﬁed in HDMI 2.0b

DisplayPort 1.4 – Requires Processor Graphics

2x Thunderbolt™ 4 (Type-C), Input from mini DisplayPort

Memory Support 2 DIMMs, Dual Channel DDR4-5600MHz(OC)

Storage 1x M.2 Gen4 x4 64Gb/s slot, 1x M.2 Gen3 x4 32Gb/s slot,

supports Intel

Optane™ technology

4x SATA 6Gb/s ports

Thunderbolt™ 4 2x USB Type-C up to 40G,

Charging support up to 5V/3A, 15W,

2x Mini DisplayPort input ports

USB ports 3 x USB 3.2 Gen 2 10Gbps (2 Type-A + 1 Type-C)

4 x USB 3.2 Gen 1 5Gbps (4 Type-A)

4 x USB 2.0

LAN

Intel

I225-V 2.5G LAN

WiFi / BT

Intel

Wi-Fi 6E AX210, Bluetooth 5.2

Audio 8-Channel(7.1) HD Audio with Audio Boost 4

FEATURES

10 Layer PCB with 2oz Thickened Copper

An Enhanced PCB design provides higher performance and long-

lasting system stability without any compromise.

Aluminum Cover

Fully aluminum IO cover provide the maximum surface of heat

dissipation, ready for breaking the world record!

Direct 8 Phases with 90A SPS

INTERSIL digital PWM, direct 8 phases with 90A Smart Power

Stage, Titanium Choke III and Core Boost to unleash the

maximum performance.

Lightning Gen4 Solution

The latest Gen4 PCI-E and M.2 solution with up to 64GB/s

bandwidth for maximum transfer speed.

Frozr Heatsink Design

Designed with double ball bearings to provide best performance

for enthusiast gamers and prosumers.

2.5G LAN

Onboard 2.5G LAN with LAN manager, delivering the best online

gaming experience.

Wi-Fi 6E

The latest wireless solution supports 6GHz spectrum, MU-MIMO

and BSS color technology, delivering speeds up to 2400Mbps.

Dual M.2 Connectors

Onboard dual M.2 connectors for the maximum storage

performance with one Lightning Gen 4 solution.

Dual Thunderbolt™ 4 ports

Thunderbolt™ 4 brings Thunderbolt to USB-C at true 40 Gb/s

speeds, 8K display support, Daisy-Chaining and Multi-Port

Accessory Architecture.

CONNECTIONS

1. DisplayPort

3. 2.5G LAN

5. Thunderbolt 4 40Gbps (Type-C)

7. Clear CMOS Button

9. USB 3.2 Gen1 5Gbps (Type-A)

11. Mini DisplayPort Input (for

Thunderbolt passthrough)

2. USB 2.0

4. Wi-Fi /Bluetooth

6. HD Audio Connectors

8. HDMI

10. USB 3.2 Gen2 10Gbps (Type-A)

Generated 2021-11-24, check for the latest version www.msi.com/datasheet. The information provided in this document is intended for informational purposes only and is subject to change without notice.
