MSI MAG X570S TOMAHAWK MAX WIFI Спецификация онлайн

МАТЕРИНСКИЕ ПЛАТЫ

MAG X570S TOMAHAWK MAX WIFI

CONQUER THE BATTLEFIELD

SPECIFICATIONS

Model Name MAG X570S TOMAHAWK MAX WIFI

CPU Support

Supports AMD Ryzen

™

5000 Series, 5000 G-Series, 4000 G-

Series, 3000 Series, 3000 G-Series, 2000 Series and 2000 G-

Series desktop processors

CPU Socket Socket AM4

Chipset AMD X570 Chipset

Graphics

Interface

2x PCIe 4.0 x16 slots

Support AMD CrossFire™ Technology

Display Interface Support 4K@60Hz as speciﬁed in HDMI 2.1

– Requires Processor Graphics

Memory Support 4 DIMMs, Dual Channel DDR4-5100 (OC)

Expansion Slots 2x PCIe 3.0 x1 slots

Storage 2x M.2 Gen4 x4 slots, 6x SATA 6Gb/s ports

USB ports 5x USB 3.2 Gen 2 10G (3 Type-A + 2 Type-C)

6x USB 3.2 Gen 1 5G (6 Type-A)

6x USB 2.0

LAN

1x Realtek

8125B 2.5G LAN

WiFi / BT

Intel

Wi-Fi 6E AX210, Bluetooth 5.2

Audio 8-Channel (7.1) HD Audio with Audio Boost 5

FEATURES

Увеличенные радиаторы

Эффективное охлаждение системы питания для стабильной

работы высокопроизводительных процессоров.

M.2 Shield FROZR

M.2 thermal accessory. Keeps M.2 SSDs safe while preventing

throttling, making them run faster.

2oz Thickened Copper PCB

An enhanced PCB design improves heat dissipation and

performance reliability.

Wi-Fi 6E

The latest wireless solution supports 6GHz spectrum, MU-MIMO

and BSS color technology, delivering speeds up to 2400Mbps.

2.5G Network Solution

Featuring premium 2.5G LAN with LAN manager to deliver better

network experience.

Core Boost

Улучшенная система питания для поддержки новых

многоядерных процессоров.

DDR4 Boost

Advanced technology to deliver pure data signals for the best

gaming performance and stability.

Audio Boost 5

Isolated audio with a high quality audio processor & amp for the

most immersive gaming experience

Lightning Gen4 Solution

The latest Gen4 PCI-E solution with up to 64GB/s bandwidth for

maximum transfer speed.

Mystic Light RGB LED

Personalize your PC with 16.8 million colors / 29 eﬀects,

controlled in one click!

CONNECTIONS

1. PS/2 Mouse / Keyboard

3. USB 3.2 Gen 1 5Gbps (Type-A)

5. 2.5G LAN Port

7. Flash BIOS Button

9. HDMI 2.1 Port

11. USB 3.2 Gen 2 10Gbps (Type-A)

2. Wi-Fi Antenna

4. USB 3.2 Gen 2 10Gbps (Type-A)

6. HD Audio Connectors

8. USB 2.0 Port

10. USB 3.2 Gen 2 10Gbps (Type-C)

12. Optical S/PDIF OUT

Generated 2021-11-09, check for the latest version www.msi.com/datasheet. The information provided in this document is intended for informational purposes only and is subject to change without notice.
