Speciﬁcations

Specifications

CPU

Supports 1st, 2nd and 3rd Gen AMD Ryzen™/ Ryzen™ with

Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with

Radeon™ Graphics/ Athlon™ with Radeon™ Vega Graphics

Desktop Processors for Socket AM4

Chipset AMD

X470 Chipset

Memory

y 4x DDR4 memory slots, support up to 64GB

 Supports DDR4 1866/ 2133/ 2400/ 2667 Mhz by JEDEC,

and 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 Mhz by

A-XMP OC MODE*

y Dual channel memory architecture

y Supports non-ECC UDIMM memory

y Supports ECC UDIMM memory

* Athlon™ with Radeon™ Vega Graphics processors support up to 2400 MHz. And

the supporting frequency of memory varies with installed processor. Please refer

www.msi.com for more information on compatible memory.

Expansion Slots

y 2x PCIe 3.0 x16 slots (PCIE_1, PCIE_4)

 1st, 2nd and 3rd Gen AMD Ryzen™ Processors support

x16/x0, x8/x8 mode

 Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD

Ryzen™ with Radeon™ Graphics Processors support x8/

x0 mode

 Athlon™ with Radeon™ Vega Graphics Processors

support x4/x0 mode

y 1x PCIe 2.0 x16 slot (PCIE_6, supports x4 mode)*

y 3x PCIe 2.0 x1 slots

* PCI_E6 slot will be unavailable when installing M.2 PCIe SSD in M2_2 slot.

Onboard Graphics

y 1x DVI-D port, supports a maximum resolution of

1920x1200@60Hz*

y 1x HDMI™ port 1.4, supports a maximum resolution of

4096x2160@30Hz*

* Only support when using Ryzen™ with Radeon™ Vega Graphics and 2nd Gen

AMD Ryzen™ with Radeon™ Graphics/ Athlon™ with Radeon™ Vega Graphics

Processors

* Maximum shared memory of 2048 MB

Continued on next page
