Содержание

• Copyright p.2
• Identifying your motherboard revision p.2
• Disclaimer p.2
• Chapter 2 hardware installation p.3
• Chapter 1 product introduction p.3
• Chapter 3 bios setup 4 p.3
• Table of contents p.3
• Chapter 4 installing the operating system and drivers 6 p.3
• Chapter 5 appendix 8 p.3
• 1 motherboard layout p.4
• Z790 ud ax z790 ud ac z790 ud p.4
• J only for z790 ud ax k only for z790 ud ac p.4
• Chapter 1 product introduction p.4
• Z790 d ddr4 p.5
• 2 box contents p.6
• Chapter 2 hardware installation p.7
• 1 installation precautions p.7
• 2 product specifications p.8
• 2 productspecifications p.8
• 3 installing the cpu and cpu cooler p.12
• A note the cpu orientation p.12
• B installing the cpu p.13
• Follow the steps below to correctly install the cpu into the motherboard cpu socket p.13
• Do not force to engage the cpu socket locking lever when the cpu is not installed correctly as this would damage the cpu and cpu socket p.13
• Be sure to install the cpu cooler after installing the cpu actual installation process may differ depending the cpu cooler to be used refer to the user s manual for your cpu cooler p.14
• C installing the cpu cooler p.14
• 4 installing the memory p.15
• Dualchannelmemoryconfiguration p.15
• 5 installing an expansion card p.16
• 6 back panel connectors p.17
• Usb 3 gen 1 port p.17
• Usb 2 1 port q flash plus port p.17
• Sma antenna connectors 2t2r j 1t1r k p.17
• Displayport jkl p.17
• Usb 2 1 port jkl p.17
• Usb 2 1 port p.17
• Ps 2 keyboard mouse port p.17
• Hdmi 2 port p.17
• Port with usb 3 gen 2x2 support p.18
• Line in rear speaker out p.18
• Usb type p.18
• Usb 3 gen 2 type a port red p.18
• Rj 45 lan port p.18
• Mic in center subwoofer speaker out p.18
• Line out front speaker out p.18
• 7 onboard buttons and leds p.19
• Quick buttons p.19
• Qflash_plus q flash plus button p.19
• Status leds p.20
• The status leds show whether the cpu memory graphics card and operating system are working properly after system power on if the cpu dram vga led is on that means the corresponding device is not working normally if the boot led is on that means you haven t entered the operating system yet p.20
• 8 internal connectors p.21
• The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start p.22
• Connectors and 2x12 main power connector p.22
• 2 atx_12v_2x4_1 2 jkl atx_12v_2x2 m atx_12v_2x4 m atx 2x2 2x4 12v power p.22
• L only for z790 ud m only for z790 d ddr4 p.22
• With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation p.22
• To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system p.22
• J only for z790 ud ax k only for z790 ud ac p.22
• 4 cpu_fan sys_fan1 2a 2b fan headers p.23
• Sys_fan3_pump system fan water cooling pump header p.23
• All fan headers on this motherboard are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis p.23
• These fan headers are not configuration jumper blocks do not place a jumper cap on the headers p.23
• The fan pump header is 4 pin and possesses a foolproof insertion design most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis the header also provides speed control for a water cooling pump please navigate to the bios setup page of gigabyte s website and search for smart fan 6 for more information p.23
• Overheating overheating may result in damage to the cpu or the system may hang p.23
• Be sure to connect fan cables to the fan headers to prevent your cpu and system from p.23
• Cpu_opt water cooling cpu fan header p.24
• The fan header is 4 pin and possesses a foolproof insertion design most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design p.24
• Led_c1 led_c2 rgb led strip headers p.24
• For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website p.24
• Connect your rgb led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 12v of this header incorrect connection may lead to the damage of the led strip p.24
• Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices p.24
• The headers can be used to connect a standard 5050 rgb led strip 12v g r b with maximum power rating of 2a 12v and maximum length of 2m p.24
• Sata3 2 3 4 5 6 7 sata 6gb s connectors p.25
• For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website p.25
• D_led1 d_led2 addressable led strip headers p.25
• To enable hot plugging for the sata ports please navigate to the bios setup page of gigabyte s website and search for sata configuration for more information p.25
• The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device the inte p.25
• The headers can be used to connect a standard 5050 addressable led strip with maximum power rating of 5a 5v and maximum number of 1000 leds p.25
• Pin no definition p.25
• No pin p.25
• Connect your addressable led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 of the addressable led strip header incorrect connection may lead to the damage of the led strip p.25
• Chipset supports raid 0 raid 1 raid 5 and raid 10 please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array p.25
• Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices p.25
• M pcie x4 ssd m pcie x2 ssd m sata ssd p.26
• M2a_cpu a a p.26
• Follow the steps below to correctly install an m ssd in the m connector step 1 locate the m connector where you will install the m ssd use a screwdriver to unfasten the screw on the heatsink and then remove the heatsink only the m2a_cpu connectors have the heatsink remove the protective film from the thermal pad on the m2a_cpu connector step 2 locate the proper mounting hole for the m ssd to be installed insert the m ssd into the m connector at an angle step 3 press the m ssd down and then use the included screw to secure it in the connector replace the heatsink and secure it to the original hole remove the protective film from the bottom of the heatsink before replacing the heatsink p.26
• Types of m ssds supported by each m connector p.26
• There are two types of m ssds m sata ssds and m pcie ssds this motherboard only supports m pcie ssds be sure to verify the type of m ssds you want to use please note that an m pcie ssd cannot be used to create a raid set with a sata hard drive please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array p.26
• M2q_sb a a p.26
• M2p_sb a a p.26
• M2a_cpu m2p_sb m2q_sb m socket 3 connectors p.26
• F_panel front panel header p.27
• Pin no definition p.28
• 5vdual p.28
• Sense_send p.28
• No pin p.28
• Mic detection p.28
• Head phone r p.28
• Head phone l p.28
• Head phone detection p.28
• F_audio front panel audio header p.28
• This header supports s pdif digital output which allows you to connect a s pdif digital audio cable to output digital audio from your motherboard to the supported audio devices for information about connecting the digital audio cable carefully read the manual for your audio devices p.28
• The front panel audio header supports high definition audio hd you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it p.28
• Spdifo p.28
• Spdif_o s pdif out header p.28
• Some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer p.28
• Pin no definition pin no definition p.29
• Vbus 17 gnd p.29
• Nc 20 no pin p.29
• Vbus 11 vbus p.29
• Header with usb 3 gen 2 support p.29
• Vbus 11 d2 p.29
• Gnd 17 ssrx2 p.29
• Tx1 13 tx2 p.29
• Gnd 14 sstx2 p.29
• Tx1 12 tx2 p.29
• Gnd 14 gnd p.29
• The header conforms to usb 3 gen 2 specification and can provide one usb port p.29
• F_u32c usb type p.29
• The header conforms to usb 3 gen 1 and usb 2 specification and can provide two usb ports for purchasing the optional 3 front panel that provides two usb 3 gen 1 ports please contact the local dealer p.29
• F_u32 usb 3 gen 1 header p.29
• Sstx1 16 gnd p.29
• D1 19 vbus p.29
• Sstx1 15 sstx2 p.29
• D1 18 ssrx2 p.29
• Ssrx1 13 gnd p.29
• Cc1 18 d p.29
• Ssrx1 12 d2 p.29
• Sbu2 20 cc2 p.29
• Sbu1 19 d p.29
• Rx1 16 rx2 p.29
• Rx1 15 rx2 p.29
• F_usb1 f_usb2 usb 2 1 headers p.30
• Com serial port header p.30
• The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer p.30
• The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer p.30
• Prior to installing the usb bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the usb bracket p.30
• Supports a thunderbol p.31
• Spi_tpm trusted platform module header p.31
• Power 3 v p.31
• The connectors are used to connect to a gigabyte thunderbol p.31
• Thb_c1 thb_c2 thunderbol p.31
• Pin no definition p.31
• No pin p.31
• Data output p.31
• Data input p.31
• Chip select p.31
• Add in card connectors p.31
• Add in card p.31
• You may connect an spi tpm trusted platform module to this header p.31
• Bat battery p.32
• Clr_cmos clear cmos jumper p.32
• Rst reset jumper p.33
• Chapter 3 bios setup p.34
• Function keys p.35
• Startup screen p.35
• Chapter 4 installing the operating system and drivers p.36
• 1 operating system installation p.36
• 2 drivers installation p.37
• Raid levels p.38
• 1 configuring a raid set p.38
• Chapter 5 appendix p.38
• Before you begin please prepare the following items p.38
• 1 configuringaraidset p.38
• Regulatory notices p.39
• United states of america federal communications commission statement p.39
• Wireless module model name ax210ngw p.41
• Wireless module approvals wireless module manufacturer intel p.41
• This equipment complies with all the requirements and other relevant provisions of radio equipment directive 2014 53 eu this equipment is suitable for home and office use in all the european community member states and efta member states the low band 5 5 5 5 ghz is for indoor use only p.41
