Gigabyte Z790M AORUS ELITE AX [19/40] Qflash_plus q flash plus button

- 19 -

QFLASH_PLUS (Q-Flash Plus Button)

Q-Flash Plus allows you to update the BIOS when your system is off (S5 shutdown state). Save the latest

BIOS on a USB thumb drive and plug it into the dedicated port, and then you can now ash the BIOS

automatically by simply pressing the Q-Flash Plus button. The QFLED will ash when the BIOS matching and

ashing activities start and will stop ashing when the main BIOS ashing is complete.

To enable the Q-Flash Plus function, please navigate to the "Unique Features" page of GIGABYTE's

website for more information.

QFLASH_PLUS

QFLED
