Makita CXT DA332DZ [2/2] Model no da332d 10mm cordless angle drill

Model No. DA332D 10MM CORDLESS ANGLE DRILL

Print Date 28/08/2017

Page 1 / 1

Please order the parts with a part number.

Item Parts No. Description I/C Qty N/O Opt. 1 Opt. 2 Note

001 319634-1 GEAR HOUSING 1

002 221570-8 SPIRAL BEVEL GEAR 6 1

003 210171-7 BALL BEARING 6800ZZ 1

004 961006-2 RETAINING RING S-10 1

005 210029-0 BALL BEARING 608ZZ 1

006 961034-7 RETAINING RING 1

007 962102-9 RETAINING RING R-22 1

011 144701-1 CARRIER COMPLETE 1

012 221572-4 SPUR GEAR 17 3

013 221569-3 INTERNAL GEAR 48 1

014 253396-0 FLAT WASHER 10 1

015 457972-4 MOTOR BRACKET 1

016 629291-0 DC MOTOR 1

017 183H38-9 HOUSING SET 1

C10 252126-6 HEX. LOCKING NUT M4-7 2

D10 INC. 35

018 853T57-8 DA332D NAME PLATE 1

019 266130-9 TAPPING SCREW BIND PT 3X16 9

020 211166-3 BALL BEARING 698DDW 1

021 961052-5 RETAINING RING S-12 1

022 227601-1 SPIRAL BEVEL GEAR 31 1

023 211423-9 BALL BEARING 6806DDW 1

025 254201-4 KEY 4 1

027 285842-5 BEARING RETAINER 36-43 1

028 763245-8 DRILL CHUCK S10 1

030 651097-8 SWITCH C3HW-3A-PLF5MS-W 1

031 450126-2 FR CHANGE LEVER 1

032 644813-5 TERMINAL 1

033 853T61-7 DA332D SERIAL NO. LABEL 1

034 457973-2 SWITCH LEVER 1

035 183H38-9 HOUSING SET 1

C10 252126-6 HEX. LOCKING NUT M4-7 2

D10 INC. 17

037 135922-6 GEAR ASSEMBLY 1

D10 INC. 2-6

01 784244-7 + BIT 2-50 1

02 346909-5 HOOK 1

03 251314-2 + SCREW M4X12 2

04 763450-7 CHUCK KEY S10 1

05 457974-0 KEY HOLDER 1
