Model No.TL065D CORDLESS ANGLE IMPACT WRENCH

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 183G43-0 HOUSING SET 1

󳢢󳢢󳢢󳢢C10 252126-6 HEX. LOCK NUT M4-7 2

󳢢󳢢󳢢󳢢D10 INC. 40

002 266130-9

TAPPING SCREW BIND PT

3X16

003 853H05-5 TL065D NAME PLATE 1

004 644813-5 TERMINAL 1

008 450126-2 FR CHANGE LEVER 1

009 450125-4 SWITCH LEVER 1

010 620690-9 LED CIRCUIT 1

011 632K57-5 SWITCH UNIT 1

󳢢󳢢󳢢󳢢D10 INC. 10

012 265409-5 + HEX. BOLT M5X30 1

013 152461-1 ANGLE HEAD COMPLETE 1

014 226720-0 ZEROL BEVEL GEAR 13 1

015 210067-2 BALL BEARING 6000ZZ 1

016 257428-5 SLEEVE 10 1

017 210067-2 BALL BEARING 6000ZZ 1

018 961006-2 RETAINING RING S-10 1

019 962105-3 RETAINING RING R-26 1

020 257429-3 SLEEVE 15 1

021 261095-0 RUBBER WASHER 21 1

022 267120-5 FLAT WASHER 15 1

023 322689-7 ANVIL 1 *

023-1 327000-8 ANVIL O 1

024 322688-9 HAMMER 1 *

024-1 326999-4 HAMMER O 1

025 216001-0 STEEL BALL 3.5 22

026 267121-3 FLAT WASHER 20 1

027 233107-9 COMPRESSION SPRING 22 1

028 629273-2 DC MOTOR 1

029 267053-4 FLAT WASHER 12 1

030 226280-2 INTERNAL GEAR 69 1

031 257187-1 RING 32 1

033 226279-7 SPUR GEAR 29 3

034 154416-2 SPINDLE COMPLETE 1 *

034-1 140K00-5 SPINDLE COMPLETE O 1

035 216002-8 STEEL BALL 4.8 2

036 211472-6 BALL BEARING 6000 1

037 322719-4 WASHER 10 1

040 183G43-0 HOUSING SET 1

󳢢󳢢󳢢󳢢C10 252126-6 HEX. LOCK NUT M4-7 2

󳢢󳢢󳢢󳢢D10 INC. 1

Please order the parts with part number. Print Date 1/9/2020
