- 12 -

Please visit GIGABYTE's website for

support lists of CPU, memory modules,

SSDs, and M.2 devices.

Please visit the Support\Utility List page on GIGABYTE's website to download the latest

version of apps.

Bundled

Software

 Norton

Internet Security (OEM version)

 LAN bandwidth management software

Operating

System

 Support for Windows 11 64-bit

 Support for Windows 10 64-bit

Form Factor

 Micro ATX Form Factor; 24.4cm x 24.4cm

* GIGABYTE reserves the right to make any changes to the product specications and product-related information without

prior notice.

B660M AORUS

PRO AX

B660M AORUS

PRO

B660M A PRO

AX DDR4

B660M AORUS

PRO DDR4
