- 9 -
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(The PCIEX4 slot conforms to PCI Express 3.0 standard.)
Storage Interface CPU:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD
support) (M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2
SSD support) (M2P_SB)
- 4 x SATA 6Gb/s connectors
Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
Intel
®
Optane
™
Memory Ready
* System acceleration with Intel
®
Optane
™
Memory can only be enabled on the M.2
connector supported by the Chipset.
USB Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available
through the internal USB header)
- 1 x USB 2.0/1.1 port on the back panel
Chipset+2 USB 2.0 Hubs:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
2 x addressable LED strip headers
2 x RGB LED strip headers
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x S/PDIF Out header
2 x Thunderbolt
™
add-in card connectors
Содержание
- B660m gaming x ax b660m gaming x b660m g x ax ddr4 1
- B660m gaming x ax ddr4 1
- B660m gaming x ddr4 1
- Rev 1101 1
- User s manual 1
- Copyright 2
- Disclaimer 2
- Identifying your motherboard revision 2
- Chapter 1 product introduction 3
- Chapter 2 hardware installation 3
- Chapter 3 bios setup 1 3
- Chapter 4 installing the operating system and drivers 3 3
- Chapter 5 appendix 5 3
- Table of contents 3
- 1 motherboard layout 4
- B660m gaming x 4
- B660m gaming x ax 4
- Chapter 1 product introduction 4
- J only for b660m gaming x ax 4
- B660m g x ax ddr4 5
- B660m gaming x ddr4 5
- L only for b660m g x ax ddr4 5
- 2 box contents 6
- 1 installation precautions 7
- Chapter 2 hardware installation 7
- 2 product specifications 8
- 2 productspecifications 8
- 3 installing the cpu and cpu cooler 12
- A note the cpu orientation 12
- B installing the cpu 13
- Do not force to engage the cpu socket locking lever when the cpu is not installed correctly as this would damage the cpu and cpu socket 13
- Follow the steps below to correctly install the cpu into the motherboard cpu socket 13
- Be sure to install the cpu cooler after installing the cpu actual installation process may differ depending the cpu cooler to be used refer to the user s manual for your cpu cooler 14
- C installing the cpu cooler 14
- 4 installing the memory 15
- Dualchannelmemoryconfiguration 15
- 5 installing an expansion card 16
- 6 back panel connectors 17
- Displayport 17
- Hdmi 2 port 17
- Sma antenna connectors 2t2r jl 17
- Usb 2 1 port 17
- Usb 2 1 port q flash plus port 17
- Usb 3 gen 1 port 17
- Audio jack configurations 18
- Front panel line out side speaker out a 18
- Front panel mic in center subwoofer speaker out a a 18
- Jack headphone 2 channel 4 channel 5 channel 7 channel 18
- Line out front speaker out 18
- Line out front speaker out a a a a 18
- Mic in rear speaker out 18
- Mic in rear speaker out a a a 18
- Optical s pdif out connector 18
- Playback device to change the default setting first 18
- Please visit gigabyte s website for details on configuring the audio software 18
- Rj 45 lan port 18
- The gigabit ethernet lan port provides internet connection at up to 2 gbps data rate the following describes the states of the lan port leds 18
- The line out jack 18
- The mic in jack 18
- This connector provides digital audio out to an external audio system that supports digital optical audio before using this feature ensure that your audio system provides an optical digital audio in connector 18
- To prevent an electrical short inside the cable connector 18
- When removing the cable connected to a back panel connector first remove the cable from 18
- When removing the cable pull it straight out from the connector do not rock it side to side 18
- You can change the functionality of an audio jack using the audio software to configure 7 channel audio you need to open the audio software and select device 18
- Your device and then remove it from the motherboard 18
- 7 internal connectors 19
- 2 atx_12v_2x4 atx 2x4 12v power connectors and 2x12 main power connector 20
- The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 20
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 20
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation 20
- 4 cpu_fan sys_fan1 2 3 fan headers 21
- All fan headers on this motherboard are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 21
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from 21
- Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices 21
- Connect your rgb led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 12v of this header incorrect connection may lead to the damage of the led strip 21
- For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website 21
- Led_c1 led_c2 rgb led strip headers 21
- Overheating overheating may result in damage to the cpu or the system may hang 21
- The headers can be used to connect a standard 5050 rgb led strip 12v g r b with maximum power rating of 2a 12v and maximum length of 2m 21
- These fan headers are not configuration jumper blocks do not place a jumper cap on the headers 21
- Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices 22
- Chipset supports raid 0 raid 1 raid 5 and raid 10 please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array 22
- Connect your addressable led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 of the addressable led strip header incorrect connection may lead to the damage of the led strip 22
- D_led1 d_led2 addressable led strip headers 22
- For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website 22
- No pin 22
- Pin no definition 22
- Sata3 4 5 6 7 sata 6gb s connectors 22
- The headers can be used to connect a standard 5050 addressable led strip with maximum power rating of 5a 5v and maximum number of 1000 leds 22
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device the inte 22
- To enable hot plugging for the sata ports please navigate to the bios setup page of gigabyte s website and search for sata configuration for more information 22
- Follow the steps below to correctly install an m ssd in the m connector step 1 locate the m connector where you will install the m ssd use a screwdriver to unfasten the screw on the heatsink and then remove the heatsink only the m2a_cpu connector has the heatsink step 2 locate the proper mounting hole based on the length of your m ssd drive if needed move the standoff to the desired mounting hole insert the m ssd into the m connector at an angle step 3 press the m ssd down and then use the included screw to secure it in the connector remove the protective film from the bottom of the heatsink then replace the heatsink and secure it to the original hole 23
- M pcie x4 ssd m pcie x2 ssd m sata ssd 23
- M2a_cpu a a 23
- M2a_cpu m2p_sb m socket 3 connectors 23
- M2p_sb a a 23
- The m connectors on the motherboard support only m pcie ssds 23
- Types of m ssds supported by each m connector 23
- F_panel front panel header 24
- Cc1 18 d 25
- F_audio front panel audio header 25
- F_u32c usb type 25
- Gnd 14 gnd 25
- Head phone detection 25
- Head phone l 25
- Head phone r 25
- Header with usb 3 gen 2 support 25
- Mic detection 25
- No pin 25
- Pin no definition 25
- Pin no definition pin no definition 25
- Rx1 15 rx2 25
- Rx1 16 rx2 25
- Sbu1 19 d 25
- Sbu2 20 cc2 25
- Sense_send 25
- Some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 25
- The front panel audio header supports high definition audio hd you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 25
- The header conforms to usb 3 gen 2 specification and can provide one usb port 25
- Tx1 12 tx2 25
- Tx1 13 tx2 25
- Vbus 11 vbus 25
- Vbus 17 gnd 25
- D1 18 ssrx2 26
- D1 19 vbus 26
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb 2 1 header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord 26
- F_u32 usb 3 gen 1 header 26
- F_usb1 f_usb2 usb 2 1 headers 26
- From the power outlet to prevent damage to the usb bracket 26
- Gnd 14 sstx2 26
- Gnd 17 ssrx2 26
- Nc 20 no pin 26
- No pin 26
- Pin no definition 26
- Pin no definition pin no definition 26
- Power 5v 26
- Ssrx1 12 d2 26
- Ssrx1 13 gnd 26
- Sstx1 15 sstx2 26
- Sstx1 16 gnd 26
- The header conforms to usb 3 gen 1 and usb 2 specification and can provide two usb ports for purchasing the optional 3 front panel that provides two usb 3 gen 1 ports please contact the local dealer 26
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 26
- Usb dx 26
- Usb dy 26
- Vbus 11 d2 26
- Chip select 27
- Com serial port header 27
- Data input 27
- Data output 27
- No pin 27
- Pin no definition 27
- Power 3 v 27
- Spi_tpm trusted platform module header 27
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 27
- You may connect an spi tpm trusted platform module to this header 27
- 5vdual 28
- Add in card 28
- Add in card connectors 28
- No pin 28
- Pin no definition 28
- Spdif_o s pdif out header 28
- Spdifo 28
- Supports a thunderbol 28
- Thb_c1 thb_c2 thunderbol 28
- The connectors are used to connect to a gigabyte thunderbol 28
- This header supports s pdif digital output which allows you to connect a s pdif digital audio cable to output digital audio from your motherboard to the supported audio devices for information about connecting the digital audio cable carefully read the manual for your audio devices 28
- Bat battery 29
- Clr_cmos clear cmos jumper 29
- Qflash_plus q flash plus button 30
- Rst_sw rst reset button reset jumper 30
- Chapter 3 bios setup 31
- Function keys 32
- Startup screen 32
- 1 operating system installation 33
- Chapter 4 installing the operating system and drivers 33
- 2 drivers installation 34
- 1 configuring a raid set 35
- 1 configuringaraidset 35
- Before you begin please prepare the following items 35
- Chapter 5 appendix 35
- Raid levels 35
- Regulatory notices 36
- United states of america federal communications commission statement 36
- Wireless module approvals 38
- Contact us 39
- Gigabyte esupport 39
- To submit a technical or non technical sales marketing question please link to https esupport gigabyte com 39
