Gigabyte H610M H DDR4 Инструкция по эксплуатации онлайн
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
H610M H DDR4
User's Manual
Rev. 1001
Содержание
- H610m h ddr4 1
- Rev 1001 1
- User s manual 1
- Copyright 2
- Disclaimer 2
- Identifying your motherboard revision 2
- Chapter 1 product introduction 3
- Chapter 2 hardware installation 3
- Chapter 3 bios setup 6 3
- Chapter 4 installing the operating system and drivers 8 3
- Table of contents 3
- 1 motherboard layout 4
- Chapter 1 product introduction 4
- H610m h ddr4 4
- 2 box contents 5
- 1 installation precautions 6
- Chapter 2 hardware installation 6
- 2 product specifications 7
- 2 productspecifications 7
- 3 installing the cpu and cpu cooler 10
- A note the cpu orientation 10
- B installing the cpu 11
- Do not force to engage the cpu socket locking lever when the cpu is not installed correctly as this would damage the cpu and cpu socket 11
- Follow the steps below to correctly install the cpu into the motherboard cpu socket 11
- Be sure to install the cpu cooler after installing the cpu actual installation process may differ depending the cpu cooler to be used refer to the user s manual for your cpu cooler 12
- C installing the cpu cooler 12
- 4 installing the memory 13
- Dualchannelmemoryconfiguration 13
- 5 installing an expansion card 14
- 6 back panel connectors 15
- After installing the hdmi device make sure to set the default sound playback device to hdmi the item name may differ depending on your operating system 15
- D sub port 15
- Device and then remove it from the motherboard 15
- For pcb rev 1 15
- Hdmi 2 port 15
- Prevent an electrical short inside the cable connector 15
- Ps 2 keyboard and ps 2 mouse port 15
- Rj 45 lan port 15
- The d sub port supports a 15 pin d sub connector and supports a maximum resolution of 1920x1200 60 hz the actual resolutions supported depend on the monitor being used connect a monitor that supports d sub connection to this port 15
- The gigabit ethernet lan port provides internet connection at up to 1 gbps data rate the following describes the states of the lan port leds for pcb rev 1 15
- The hdmi port supports hdcp 2 and dolby truehd and dts hd master audio formats it also supports up to 192khz 24bit 7 channel lpcm audio output 15
- The usb 3 gen 1 port supports the usb 3 gen 1 specification and is compatible to the usb 2 specification use this port for usb devices 15
- The usb port supports the usb 2 1 specification use this port for usb devices 15
- Usb 2 1 port 15
- Usb 3 gen 1 port 15
- Use the upper port green to connect a ps 2 mouse and the lower port purple to connect a ps 2 keyboard 15
- When removing the cable connected to a back panel connector first remove the cable from your 15
- When removing the cable pull it straight out from the connector do not rock it side to side to 15
- You can use this port to connect your hdmi supported monitor the maximum supported resolution is 4096x2160 30 hz but the actual resolutions supported are dependent on the monitor being used 15
- Audio jack configurations 16
- Line in rear speaker out blue 16
- Line out front speaker out green 16
- Mic in center subwoofer speaker out pink 16
- Please visit gigabyte s website for details on configuring the audio software 16
- The line in jack use this audio jack for line in devices such as an optical drive walkman etc 16
- The line out jack 16
- The mic in jack 16
- You can change the functionality of an audio jack using the audio software to configure 7 channel audio access the audio software for audio settings 16
- 7 internal connectors 17
- 2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 18
- The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 18
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 18
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation 18
- 4 cpu_fan sys_fan1 sys_fan2 fan headers 19
- All fan headers on this motherboard are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 19
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from 19
- Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices 19
- Connect your rgb led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 12v of this header incorrect connection may lead to the damage of the led strip 19
- For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website 19
- Led_c rgb led strip header 19
- Overheating overheating may result in damage to the cpu or the system may hang 19
- The header can be used to connect a standard 5050 rgb led strip 12v g r b with maximum power rating of 2a 12v and maximum length of 2m 19
- These fan headers are not configuration jumper blocks do not place a jumper cap on the headers 19
- Follow the steps below to correctly install an m ssd in the m connector step 1 locate the proper mounting hole for the m ssd to be installed and then install the mounting clip first step 2 slide the m ssd into the connector at an angle step 3 press the m ssd down and then secure it by pressing the clip pin into the mounting hole 20
- M pcie x4 ssd m pcie x2 ssd m sata ssd 20
- M2p_sb a a 20
- M2p_sb m socket 3 connector 20
- Pin no definition 20
- Sata3 4 5 6 7 sata 6gb s connectors 20
- The m connector on the motherboard supports only m pcie ssds 20
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device 20
- To enable hot plugging for the sata ports please navigate to the bios setup page of gigabyte s website and search for sata configuration for more information 20
- Types of m ssds supported by each m connector 20
- F_panel front panel header 21
- D1 18 ssrx2 22
- D1 19 vbus 22
- F_audio front panel audio header 22
- F_u32 usb 3 gen 1 header 22
- Gnd 14 sstx2 22
- Gnd 17 ssrx2 22
- Head phone detection 22
- Head phone l 22
- Head phone r 22
- Mic detection 22
- Nc 20 no pin 22
- No pin 22
- Pin no definition 22
- Pin no definition pin no definition 22
- Sense_send 22
- Some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 22
- Ssrx1 12 d2 22
- Ssrx1 13 gnd 22
- Sstx1 15 sstx2 22
- Sstx1 16 gnd 22
- The front panel audio header supports high definition audio hd you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 22
- The header conforms to usb 3 gen 1 and usb 2 specification and can provide two usb ports for purchasing the optional 3 front panel that provides two usb 3 gen 1 ports please contact the local dealer 22
- Vbus 11 d2 22
- Com serial port header 23
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb 2 1 header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord 23
- F_usb1 f_usb2 usb 2 1 headers 23
- From the power outlet to prevent damage to the usb bracket 23
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 23
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 23
- After system restart go to bios setup to load factory defaults select load optimized defaults or 24
- Always turn off your computer and unplug the power cord from the power outlet before clearing 24
- Chip select 24
- Clr_cmos clear cmos jumper 24
- Data input 24
- Data output 24
- Manually configure the bios settings please navigate to the bios setup page of gigabyte s website for more information 24
- No pin 24
- Open normal 24
- Pin no definition 24
- Power 3 v 24
- Short clear cmos values 24
- Spi_tpm trusted platform module header 24
- The cmos values 24
- Use this jumper to clear the bios configuration and reset the cmos values to factory defaults to clear the cmos values use a metal object like a screwdriver to touch the two pins for a few seconds 24
- You may connect an spi tpm trusted platform module to this header 24
- Bat battery 25
- Chapter 3 bios setup 26
- Function keys 27
- Startup screen 27
- Chapter 4 installing the operating system and drivers 28
- Regulatory notices 29
- United states of america federal communications commission statement 29
- Contact us 30
- Gigabyte esupport 30
- To submit a technical or non technical sales marketing question please link to https esupport gigabyte com 30
