![Gigabyte H610M H DDR4 [4/30] 1 motherboard layout](/img/pdf.png)
Gigabyte H610M H DDR4 [4/30] 1 motherboard layout
![Gigabyte H610M H DDR4 [4/30] 1 motherboard layout](/views2/1919697/page4/bg4.png)
- 4 -
1-1 Motherboard Layout
Chapter 1 Product Introduction
Temperature sensor
KB_MS
CPU_FAN
SYS_FAN1
LGA1700
ATX
H610M H DDR4
F_AUDIO
COM
LED_C
AUDIO
BAT
ATX_12V_2X4
Intel
®
H610
R_U32
CODEC
CLR_CMOS
M_BIOS
VGA
HDMI
USB_LAN
PCIEX16
80 60
PCIEX1
iTE
®
Super I/O
GbE LAN
Chip
F_USB1
F_PANEL
SPI_TPM
F_U32
DDR4_2
DDR4_1
M2P_SB
6 7
4 5
SATA3
R_USB20
F_USB2
SYS_FAN2
USB 2.0 Hub
