Asus ROG STRIX Z690-G GAMING WIFI [12/74] Installation tools and components

xii

Installation tools and components

Phillips (cross) screwdriver

PC chassis Power supply unit

Intel

LGA 1700 CPU Intel

LGA 1700 compatible CPU Fan

DDR5 DIMM SATA hard disk drive

SATA optical disc drive (optional) Graphics card (optional)

M.2 SSD module (optional) 1 Bag of screws

The tools and components in the table above are not included in the motherboard

package.
