ROG CROSSHAIR X670E Series BIOS Manual

Содержание

Motherboard 1
E20466 first edition october 2022 2
Contents 3
An error message appears on the screen during the system bootup and requests you to run the bios setup 4
Bios basic input and output system stores system hardware settings such as storage device configuration overclocking settings advanced power management and boot device configuration that are needed for system startup in the motherboard cmos in normal circumstances the default bios settings apply to most conditions to ensure optimal performance do not change the default bios settings except in the following circumstances 4
Bios setup 4
Knowing bios 4
Rog crosshair x670e series bios manual 4
You have installed a new system component that requires further bios settings or update 4
Bios menu screen 5
Bios setup program 5
Entering bios at startup 5
Entering bios setup after post 5
Hotkey 5
Key to enter bios 5
Post continues with its routines 5
Press the power button to turn the system off then back on do this option only if you failed to enter bios setup using the first two options 5
Press the reset button on the system chassis 5
Rog crosshair x670e series bios manual 5
Simultaneously 5
To enter bios setup after post 5
Use the bios setup to update the bios or configure its parameters the bios screen include navigation keys and brief onscreen help to guide you in using the bios setup program 5
Advanced mode 6
Rog crosshair x670e series bios manual 6
The advanced mode provides advanced options for experienced end users to configure the bios settings the figure below shows an example of the advanced mode refer to the following sections for the detailed configurations 6
The default screen for entering the bios setup program can be changed refer to the setup mode item in section boot menu for details 6
Language 7
Menu bar 7
Menu items 7
Myfavorite 7
Qfan control 7
Submenu items 7
Ai oc guide 8
Configuration fields 8
General help 8
Hot keys 8
Last modified button 8
Resize bar 8
Scroll bar 8
Search 8
Ez mode 9
Hotkey 9
Hotkey for the advanced bios settings 9
Rog crosshair x670e series bios manual 9
The boot device options vary depending on the devices you installed to the system 9
Qfan control 10
Rog crosshair x670e series bios manual 10
The qfan control allows you to set a fan profile or manually configure the operating speed of your cpu and chassis fans 10
Configuring fans manually 11
Ai oc guide 12
Clicking on enable ai will enable ai overclocking 12
Rog crosshair x670e series bios manual 12
The ai oc guide allows you to enable the ai overclocking feature or view a quick guide of the ai overclocking feature which highlights the recommended setup procedure and descriptions of the ai overclocking 12
The screenshot shown in this section is for reference purposes only and may not exactly match what you see on your screen 12
This function is only enabled when using an unlocked cpu 12
My favorites 13
Adding items to my favorites 14
Main menu 15
Security 15
Administrator password 16
User password 16
Ai overclock tuner 17
Extreme tweaker menu 17
Allows you to select your asus enhanced memory profile aemp each profile has its own dram frequency timing and voltage 18
Allows you to select your d o c p profile each profile has its own dram frequency timing and voltage 18
Allows you to select your expo wprofile each profile has its own dram frequency timing and voltage 18
Bclk1 frequency 18
Bclk2 frequency 18
Configuration options auto synchronous mode asynchronous mode 18
D o c p 18
Eclk mode 18
Forces a ddr5 frequency slower than the common tck detected via spd 18
Memory frequency 18
Rog crosshair x670e series bios manual 18
To adjust the value 18
To adjust the value the values range from 80 mhz to 200 mhz with an interval of 0 50mhz configuration options auto 80 000 200 000 18
Core performance boost 19
Cpu core ratio 19
Cpu core ratio per ccx 19
Fclk frequency 19
Preference 19
Dram timing control 20
Precision boost overdrive 22
Configuration options 0 256 24
Curve optimizer 24
Gfx curve optimizer 24
Platform thermal throttle limit 24
Rog crosshair x670e series bios manual 24
Digi vrm 25
Performance bias 30
Tweaker s paradise 30
Core flex 31
Ai features 32
Cpu core voltage 32
Cpu core voltage offset 33
Cpu core voltage override 33
Cpu soc voltage 33
Cpu vddio mc voltage 33
Offset mode sign 33
Vddsoc offset mode sign 33
Vddsoc voltage offset 33
Vddsoc voltage override 33
Dram vdd voltage 34
Dram vddq voltage 34
High dram voltage mode 34
Misc voltage 34
Misc voltage offset 34
Misc voltage override 34
Offset mode sign 34
Vddio override 34
Vddp voltage 34
Advanced memory voltages 35
Advanced menu 36
Rog crosshair x670e series bios manual 36
The advanced menu items allow you to change the settings for the cpu and other system devices scroll down to display other bios items 36
Endorsement hierarchy 37
Pending operation 37
Platform hierarchy 37
Security device support 37
Sha256 pcr bank 37
Storage hierarchy 37
Trusted computing 37
Amd ftpm configuration 38
Disable block sid 38
Erase ftpm nv for factory reset 38
Firmware tpm switch 38
Physical presence spec version 38
Cpu configuration 39
Nx mode 39
Pss support 39
Svm mode 39
Above 4g decoding 40
Allows you to enable or disable 64bit capable devices to be decoded in above 4g address space only if system supports 64 bit pci decoding configuration options disabled enabled 40
Allows you to enable or disable single root io virtualization support if the system has sr iov capable pcie devices configuration options disabled enabled 40
If the system has resizable bar capable pcie devices this option enables or disables resizable bar support only if system supports 64 bit pci decoding configuration options disabled enabled 40
Pci subsystem settings 40
Re size bar support 40
Rog crosshair x670e series bios manual 40
Sr iov support 40
The items in this menu allow you to configure pci pci x and pci express settings 40
Legacy usb support 41
Mass storage devices 41
Usb configuration 41
Usb mass storage driver support 41
Xhci hand off 41
Allows you to enable or disable the individual usb ports 42
Configuration options disabled enabled 42
Ipv4 ipv6 pxe support 42
Network stack 42
Network stack configuration 42
Nvme configuration 42
On a connected nvme device which appears in this menu to view more information on the nvme device 42
Rog crosshair x670e series bios manual 42
The items in this menu allow you to change the network stack configuration 42
Usb single port control 42
Hdd ssd smart information 43
Rog crosshair x670e series bios manual 43
The items in this menu allow you to view the smart information for connected storage devices 43
Nvme raid mode 44
Sata configuration 44
Sata controller s 44
Sata mode 44
Smart self test 44
Apm configuration 45
Erp ready 45
Max power saving 45
Power on by pci e 45
Restore ac power loss 45
Sata6g 45
Sata6g hot plug 45
Onboard devices configuration 46
Pciex16_1 bandwidth bifurcation configuration 46
Power on by rtc 46
Bluetooth controller 47
Led lighting 47
Pciex16_2 bandwidth bifurcation configuration 47
Q code led function 47
Usb audio controller 47
When system is in sleep hibernate or soft off states 47
When system is in working state 47
Wi fi controller 47
Asm1061 configuration 48
G lan card 48
Intel lan controller 48
Pcie link speed 48
Serial port configuration 48
U32g2_c3 type c power mode 48
Usb power delivery in soft off state s5 48
Amd cbs 49
Global c state control 49
Nb configuration 49
Primary video device 49
Uma frame buffer size 49
Allows you to enable or disable pfeh cloack individual banks and mask deferred error interrupts from each bank configuration options enabled disabled auto 50
Can be used to disable symmetric multithreading to re enable smt a power cycle is needed after setting this item to auto configuration options disable auto 50
Configuration options disabled auto 50
Core performance boost 50
Core watchdog 50
Cpu common options 50
Performance 50
Platform first error handling 50
Prefetcher settings 50
Rog crosshair x670e series bios manual 50
Smt control 50
Thread enablement 50
Action on bist failure 52
Allows you to set the action to take when a ccd bist failure is detected configuration options do nothing down ccd auto 52
Amount of memory to cover 52
Control secure memory enryption enable configuration options disable enable auto 52
Df common options 52
Disable df to external downstream ip sync flood propagation 52
Disables error propagation to umc or any downstream slaves eg fch use this to avoid reset in failure scenario configuration options sync flood disabled sync flood enabled auto 52
Memory addressing 52
Rog crosshair x670e series bios manual 52
Snp memory rmp table coverage 52
Specify mb of system memory to be covered in hex configuration options 0 100000 52
When this item is set to enabled the entie system memory is covered configuration options disabled enabled custom auto 52
Configuration options false true 53
Ddr options 53
Df cstates 53
Disable df sync flood propagation 53
Disables propagation from pie to other df components and eventually to sdp ports configuration options sync flood disabled sync flood enabled auto 53
Freeze df module queues on error 53
Psp error injection support 53
Rog crosshair x670e series bios manual 53
This item allows you to enable or disable freezing of all df queues on error and also forces a sync flood on hwa even if mcas are disabled configuration options disabled enabled auto 53
Umc common options 53
When df cstate feature is set to enabled fw programs the registers required to enable this feature is the df hw for auto option it means this option will synchronize with global c state configuration options disabled enabled auto 53
Rog crosshair x670e series bios manual 54
Rog crosshair x670e series bios manual 55
Rog crosshair x670e series bios manual 56
Rog crosshair x670e series bios manual 57
Rog crosshair x670e series bios manual 58
Rog crosshair x670e series bios manual 59
Nbio common options 60
Rog crosshair x670e series bios manual 60
Rog crosshair x670e series bios manual 61
Smu common options 61
Rog crosshair x670e series bios manual 62
Rog crosshair x670e series bios manual 63
Amd pbs 64
Graphics features 64
Thunderbolt usb4 mmio resource 65
Thunderbolt usb4 security level 65
Thunderbolt usb4 support 65
Thunderbolt usb4 wake up command 65
Amd overclocking 66
Cpu core count control 66
Cpu frequency 66
Cpu voltage 66
Manual cpu overclocking 66
Rog crosshair x670e series bios manual 66
Specifies a custom cpu core frequency should be combined with a custom cpu voltage power saving features for idle cores e g cc6 sleep remain active 66
Specifies a custom cpu core voltage mv should be combined with a custom cpu voltage power saving features for idle cores e g cc6 sleep remain active stepping is 5mv 66
The items in this menu shows the amd overclocking setup page 66
Ddr and infinity fabric frequency timings 67
Ddr options 67
Rog crosshair x670e series bios manual 67
Rog crosshair x670e series bios manual 68
Rog crosshair x670e series bios manual 69
Rog crosshair x670e series bios manual 70
Rog crosshair x670e series bios manual 71
Infinity fabric frequency and dividers 72
Rog crosshair x670e series bios manual 72
Precision boost overdrive 73
Allows the user to decrease the maximum allowed processor temperature celsius configuration options manual auto 74
Configuration options 0 255 74
Gfx curve optimizer 74
Max cpu boost clock override 74
Platform thermal throttle ctrl 74
Platform thermal throttle limit 74
Rog crosshair x670e series bios manual 74
To adjust the value the values range from 25 to 200 with an interval of 25 configuration options auto 0 200 74
Curve optimizer 75
Global vddg ccd voltage 75
Global vddg iod voltage 75
Rog crosshair x670e series bios manual 75
Vddg ccd represents voltage for the data portion of the infinity fabric range is 650mv 1650mv stepping is 10mv 75
Vddg iod represents voltage for the data portion of the infinity fabric range is 650mv 1650mv stepping is 10mv 75
Vddg represents voltage for the data portion of the infinity fabric it is derived from the cpu soc uncore voltage vdd_soc vddg can approach but not exceed vdd_soc configuration options auto global vddg voltage control per ccd vddg voltage control 75
Vddg voltage control 75
Ln2 mode 76
Soc uncore oc mode 76
Soc voltage 76
Vdd misc 76
Vddp voltage control 76
Allows you to set the maximum lclk frequency configuration options 1029 2500 77
Auto use default settings manual manually configure lclk frequency 77
Lclk frequency control 77
Maximum frequency 77
Onboard voltage control 77
Rog crosshair x670e series bios manual 77
Specifies the vdd misc voltage in mv definitely follow svi3 type 2 slave vid 500 5600mv step 10mv configuration options 500 5600 77
Vdd misc voltage 77
Vddio voltage control 77
Array management 78
Controller management 78
Create array 78
Performs a rescan of all physical disks and arrays connected to this controller 78
Raidxpert2 configuration utility 78
Rescan disks 78
Rog crosshair x670e series bios manual 78
The items in this menu allow you to configure raidxpert2 controller 78
This item allows you to create an array 78
This item allows you to view information on the controller 78
This submenu allows you to manage controller properties 78
This submenu displays array properties and allows you to perform operations such as creating or deleting arrays 78
View controller information 78
Vpp voltage control 78
Physical disk management 79
Fan speed monitor 80
Monitor menu 80
Temperature monitor 80
Q fan configuration 81
Voltage monitor 81
Chassis fan s configuration 83
Cpu fan point1 duty cycle 83
Cpu fan point1 temperature 83
Cpu fan point2 duty cycle 83
Cpu fan point2 temperature 83
Keys to adjust the point1 temperature 83
Keys to adjust the point2 temperature 83
Rog crosshair x670e series bios manual 83
Rog crosshair x670e series bios manual 84
Allows you to configure the csm compatibility support module items to fully support the various vga bootable devices and add on devices for better compatibility 89
Boot menu 89
Csm compatibility support module 89
Enabled for better compatibility enable the csm to fully support the non uefi driver add on devices or the window 89
Launch csm 89
Rog crosshair x670e series bios manual 89
The boot menu items allow you to change the system boot options 89
Uefi mode 89
Uefi mode disabled disable the csm to fully support the non uefi driver add on devices or the window 89
Secure boot 90
Db management 91
Kek management 91
Rog crosshair x670e series bios manual 91
The db authorized signature database lists the signers or images of uefi applications operating system loaders and uefi drivers that you can load on the single computer 91
The kek key exchange key or key enrollment key manages the signature database db and revoked signature database dbx 91
Allows you to enable or disable boot with initialization of a minimal set of devices required to launch active boot option has no effect for bbs boot options configuration options disabled enabled 92
Allows you to select a desired additional post waiting time to easily enter the bios setup you can only execute the post delay time during normal boot configuration options 0 sec 10 sec 92
Auto automatically adjust the boot logo size for windows requirements full screen maximize the boot logo size disabled hide the logo during post 92
Boot configuration 92
Boot logo display 92
Dbx management 92
Fast boot 92
Next boot after ac power loss 92
Normal boot returns to normal boot on the next boot after an ac power loss fast boot accelerates the boot speed on the next boot after an ac power loss 92
Post delay time 92
Rog crosshair x670e series bios manual 92
The dbx revoked signature database lists the forbidden images of db items that are no longer trusted and cannot be loaded 92
Boot option priorities 93
Boot override 93
Bios image rollback support 94
Flexkey 94
Publish hii resources 94
Setup animator 94
Tool menu 94
Asus ez flash 3 utility 95
Asus secure erase 95
Asus secure erase on the advanced mode menu 95
Rog crosshair x670e series bios manual 95
Ssd speeds may lower over time as with any storage medium due to data processing secure erase completely and safely cleans your ssd restoring it to factory performance levels 95
To confirm your choice 95
Asus user profile 96
Load from profile 96
Load save profile from to usb drive 96
Profile name 96
Save to profile 96
Asus armoury crate 97
Asus spd information 97
Download install armoury crate app 97
Download install myasus service app 98
Myasus 98
Discard changes exit 99
Exit menu 99
Launch efi shell from usb drives 99
Load optimized defaults 99
Save changes reset 99
Asus ez flash 3 100
Updating bios 100
Asus crashfree bios 3 101
Recovering the bios 101
Rog crosshair x670e series bios manual 102

Asus ROG CROSSHAIR X670E EXTREME [102/102] Rog crosshair x670e series bios manual

Содержание

Похожие устройства
