STATUS JS750M [6/27] Technical specifications
10 11
EN
DUST EXTRACTION ADAPTOR
The dust extraction adaptor (16) allows a dust extraction system or a household vacuum
cleaner to be connected to the tool in order to remove dust whilst the tool is in use.
Warning: Do not use a dust extraction system or a vacuum cleaner when cutting metal.
Sparks may ignite residual wood dust.
MAKING A CUT
• Switch on the jigsaw and allow the blade to reach maximum speed.
• Slowly guide the jigsaw forward using both hands, keeping the shoe plate at against
the work piece.
• Do not force the jigsaw.
Note: Use only enough pressure to keep the blade cutting. Do not force the cutting, allow
the blade and the sawto do the work.
POCKET & ROUND CUTTING
• When starting a cut from the centre of a work piece, drill a 12 mm diameter hole to
ensure that there is clearance for the blade.
• When cutting tight curves, reduce the speed of the saw.
Warning: Do not move the saw forward along its cut until the blade has completely
entered the material and the shoe comes to rest on its surface.
CUTTING METAL
• When cutting metals, a suitable cooling/cutting oil must be used.
• Squirt the lubricant onto the blade or work piece at regular intervals during cutting in
order to reduce wear of the blade.
GENERAL INSPECTION
Regularly inspect all fasteners and ensure they are properly tightened. Should any of the
screws be loose, retighten it immediately to avoid hazards.
If the replacement of the supply cord is necessary, this has to be done by the manufacturer
or his agent in order to avoid a safety hazard.
CLEANING
For safe operation always keep the machine and its ventilation slots clean.
Regularly check to see if any dust or foreign matter has entered the ventilation slots and the
grills around the switches. Use a soft brush and/or air jet to remove any accumulated dust.
Wear safety glasses to protect your eyes whilst cleaning.
Exterior plastic parts may be cleaned with a damp cloth and mild detergent if necessary.
MAINTENANCE
MAINTENANCE
EN
TECHNICAL SPECIFICATIONS
The manufacturer reserves the right to make changes and improvements to the products and to
alter specications without prior notice.
Includes:
Parallel guide, saw blade, foot cover, 2xbatteries, dust adapter, anti-burr plate.
TECHNICAL SPECIFICATIONS
Model JS750M
Voltage 220-240 V~ 50 Hz
Input power 750 W
No load speed 0-3000/min.
Max. cutting capacity
- wood 120 mm
- steel/aluminum 8/12 mm
Stroke length 26 mm
Blade type T
Weight 2,9 kg
А-weighted sound pressure level L
pA
85 db(A), uncertainty 5 dB(A)
А-weighted sound power level L
wA
96 dB(A), uncertainty 5 dB(A)
Vibration emission value a
hb
/a
hm
9.48/10.75 m/s
2,
uncertainty 1,5 m/s
2
Protection class
II
WARNING!
Never use alcohol, petrol or other cleaning agent. Never use caustic agents to
clean plastic parts. Water must never come into contact with the tool.
REPLACEMENT PARTS
To assure product safety and reliability, repairs, maintenance and adjustment (including
brush inspection and replacement) should be performed by authorised service centres
always using genuine replacement parts.
