ASRock Z690 PG Velocita [12/128] English
![ASRock Z690 PG Velocita [12/128] English](/views2/1921025/page12/bgc.png)
English
4
1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
802.11ax Wi-Fi 6E Module
•
Supports IEEE 802.11a/b/g/n/ax
•
Supports Dual-Band 2x2 160MHz with extended 6GHz
band* support
* Wi-Fi 6E (6GHz band) will be supported by Microso® Win-
dows® 11. e availability will depend on the dierent regula-
tion status of each country and region. It will be activated (for
supported countries) through Windows Update and soware
updates once available.
* A 6GHz compatible router is required for 6E functionality.
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth + High speed class II
•
Supports MU-MIMO
•
Supports Killer LAN Soware
•
Supports Killer DoubleShot™ Pro
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x Optical SPDIF Out Port
•
1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports
ESD Protection)
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports
ESD Protection)
•
6 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)
* USB3_34 are from Intel® Z690; USB3_12 are from ASMedia
ASM3042.
* USB3_23 are the Lightning Gaming Ports.
* Ultra USB Power is supported on USB3_34 ports.
* ACPI wake-up function is not supported on USB3_34 ports.
