ASRock X670E Taichi Carrara [6/86] Memory
![ASRock X670E Taichi Carrara [6/86] Memory](/views2/1921097/page6/bg6.png)
English
2
1.2 Specications
Platform
•
EATX Form Factor
•
8 Layer PCB
CPU
•
Supports AMD Socket AM5 Ryzen
TM
7000 Series Processors
•
Supports ASRock Hyper BCLK Engine
Chipset
•
AMD X670
Memory
•
Dual Channel DDR5 Memory Technology
•
4 x DDR5 DIMM Slots
•
Supports DDR5 non-ECC, un-buered memory up to
6600+(OC)*
•
Max. capacity of system memory: 128GB
•
Supports Extreme Memory Prole (XMP) and EXTended
Proles for Overclocking (EXPO) memory modules
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
Expansion
Slot
CPU:
•
2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/
x8 modes*
Chipset:
•
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT
PCIe WiFi module
* Supports NVMe SSD as boot disks
•
Supports AMD CrossFire
TM
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD RDNA
TM
2 graphics (Actual support may
vary by CPU)
•
1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR,
HDCP 2.3 and max. resolution up to 4K 120Hz
•
2 x USB4, support HDCP 2.3 and max. resolution up to 8K
60Hz*
