47
B650M PG Riptide WiFi
underbolt AIC Connector
(5-pin TB1) (see p.6, No. 27)
Please connect a underbolt
TM
add-in card (AIC) to the underbolt AIC connector via
the GPIO cable.
*Please install the underbolt
TM
AIC card to PCIE4 (default slot).
*For the underbolt compatibility and limitation, please visit www.asrock.com.
B6 50 M PG
W Fi i
R I PT I D E
TB1
1
