CONTROLS FOR REFRIGERATOR COMPARTMENT

The default setting of the temperature control button for

the refrigerator compartment is NORMAL.

To control the refrigerator temperature, press the REF.

TEMP CONTROLbutton.

When the button is pressed, the LEDs light.

The temperature is set in 5 steps, from MIN to MAX.

OPERATIONS

STARTING

When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures

prior to filling it with fresh or frozen foods.

If operation is interrupted, wait 5 minutes before restarting.

REF. TEMP. CONTROL

MIN MAX

CONTROLS FOR FREEZER COMPARTMENT

●

The higher number the control setting is, the lower the

temperature of the freezer compartment becomes.

●

Since the temperature of the refrigerator and freezer compartments is controlled with a fixed amount of

cooled air, compartment becomes colder.the refrigerator compartment will be warmer if the freezer

●

When the freezer compartment is not cold enough in winter, adjust the control for the freezer to High(4~7).

●

Setting the Freezer Knob at will satisfy 4 STAR. Setting the Freezer Knob at NORMAL will have

sufficient freezing effect, so it is recommended to set the Knob at NORMAL.

24 3

FREEZER CONTROL

FREEZER MIN

NORMAL

FREEZER MAX

Ref. Temp Control Button

Model : GR-B628***/B528***

24 3

FREEZER CONTROL

FREEZER MIN

NORMAL

FREEZER MAX

Model : GR-B492***
