6
Operation
Starting
When your refrigerator is first installed, allow it 24 hours to stabilize at normal operating
temperatures prior to filling it with fresh or frozen foods. Then adjust the knobs to get satisfactory
results as per instruction given below. If operation is interrupted, allow 5 minutes delay before
restarting.
•
Your refrigerator has two controls that let you regulate the temperature in the freezer and
refrigerator compartments.
•
Initially set the Refrigerator Temp. Control Med/normal and the Freezer Temp. Control at Normal
Leave it operating for 24 hours (one day) to stabilize. Then adjust the compartment temperature
• Refrigerator Temp. Control (MIN, MED/NORMAL) 1, 2, 3, 4, 5, 6, 7 MIN, MED, MAX The higher the
setting, the colder the refrigerator compartment will become.
• Freezer Temp. Control - 1, 2, 3, 4, 5, 6, 7, 8, 9 Setting at "9", the freezer compartment becomes
coldest. But the refrigerator compartment becomes warmer because less cold air flows into the
.
1. Temperature Control
r Refrigerator
r FREEZER
3
4
5
6 7
FREEZER TEMP. CONTROL
FRIDGE MAX.
NORMAL.
FREEZER MAX.
1
5/6
7
MAX
X- FOR EXTRA FRIDGE COOLING
Med
Min
Max
l
o
r
t
n
o
c
T
e
e
r
m
p
u
t
a
e
r
MAX
NORMAL
MIN
Ice Trays
Bank Ice
Normal
Water
Level
If you keep a lot of foods in the freezer or open its door frequently, its temperature could go higher.
In this case, set the Freezer Temp. Control dial between 7 and 9 to cool it. Return the Freezer Temp.
Control dial to the original position after usage.
•
For colder refrigerator turn the Freezer Temp. Control to "1"~"3" to direct more cold air into the
refrigerator compartment, and the refrigerator temp. Control towards max.
Setting at "6"~"7" of the Freezer Temp. Control, the refrigerator compartment will not be cold
enough.
,
2. Ice Making: Kindly check whether appliance has normal type or twisting ice serve type.
l To make ice cubes, fill the ice tray with water till
the water level mark and place it on the Ice cube
box. Then insert the ice cubes box in the freezer
compartment.
l To remove ice cubes, hold the tray at its ends and
twist gently, ice cubes fall automatically.
•
• In cold weather the unit operates less and the freezer compartment has a tendency to warm up.
For colder freezer, turn the Freezer Temp. Control to "6"~"7".& Refrigerator Temp. Control to 1 or
minimum. For warmer refrigerator, Please put the Freezer Temp. Control to 1~2 and Refrigerator
Temp. Control To 1 or minimum.
In hot weather or to put much foods in the refrigerator compartment, the refrigerator
compartment has a tendency to warm up.
Normal Type
r FREEZER
5
6
7
8 9
FREEZER TEMP. CONTROL
FRIDGE MAX.
NORMAL.
FREEZER MAX.
1
8
9
MAX
X- FOR EXTRA FRIDGE COOLING
Med
Min
Max
l
o
r
t
n
o
c
T
e
e
r
m
p
u
t
a
e
r
MAX
NORMAL
MIN
For "T" Class
according to your desire.
refrigerator compartment.
