Operation
10
Audio parameter setting
Press EQ or SELECT button
repeatedly to select a parameter:
BAS (bass) => TRE (treble) => BAL
(balance) => FAD (fader) => LOUD
ON/OFF => EQ (equalizer) => ST/
MONO (stereo or mono). Rotate
VOLUME knob to adjust each mode:
• Bass/Treble: from -7 to 7;
• Balance: L07 (left) to R07 (right);
• Fader: from R07 (rear) to F07
(front).
• Loudness: see “Loudness”
paragraph above.
• EQ: select ROCK/POP/CLASS/
JAZZ equalizer mode.
When equalizer is in any mode
except OFF, bass and treble are not
adjustable.
Preset equalizer modes
IN USB/SD playback mode press
SELECT button repeatedly until
ROCK/POP/CLASS or JAZZ equalizer
mode is displayed. Rotate VOLUME
regulator to select equalizer mode.
Clock
Press and hold BND/CLK button
to display the time on the screen.
Then press and hold this button
again; the hour indication will blink.
Rotate VOLUME regulator to adjust
hours; press BND/CLK button to go
to minutes; rotate VOLUME regulator
to adjust minutes. To confirm the
adjustment, press BND/CLK button or
leave the unit idle for several seconds.
AUX input
AUX-in jack is intended for
connecting an external audio
equipment to amplify the sound. If
connection is made correctly, the
audio signal from the external source
will be translated through the acoustics
of the head unit. This enables to
adjust the volume and quality of the
sounding. For example, you can
connect an MP3-player to listen to
tracks using the car acoustic system.
Radio operations
Band select
In Radio mode press BND/CLK
button to select a radio band: F1
(FM1), F2 (FM2), F3 (FM3). 6 stations
can be saved in each band.
Manual/automatical tuning
• Press / buttons
repeatedly to adjust the needed
frequency manually.
• Press and hold or
button. The radio will seek to the next
down or up strong and clear frequency
station.
Storing and recalling stations
• Press and hold APS button for
more than 2 seconds to automatically
find and store 6 strongest stations in
the current band.
• After 6 strongest stations are
saved, press APS button; scanning of
all stored stations will begin.
• Press buttons 1-6 to select saved
channels. If you want to save a new
station in a preset position, select
corresponding station number with
1-6 buttons. Then tune to the needed
frequency as described in “Manual/
automatical tuning“ above and press
