HYUNDAI ELECTRONICS H-CMD4005 [6/89] Detachable control panel

Detachable control panel

Detaching the front panel

1. Press the REL button to remove the panel.

Attaching the control panel

1. Insert the left side of the control panel into the main unit.

2. Press the control panel on to the right side of middle of

it until a “click” sound is heard.

Caution:

DO NOT insert the control panel from the right side. It can damage the control panel.

The control panel can easily be damaged by shocks. After removing it, place it in a protective case and be

careful not to drop it or subject it to strong shocks.

The rear connector that connects the main unit and the control panel is an extremely important part. Be careful

not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.

Note:

If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton

swab soaked in isopropyl alcohol to clean the socket on the back of the control panel.
