8
Panel controls
Front panel
1. EJECT button (
): press it to flip down the front panel and eject the CD.
2. OK button: press it in the menu to confirm settings.
3. VOL+/- buttons: press to increase/decrease volume step by step.
TUN-/TUN+ buttons: use these buttons to enter the manual tuning mode/ seek tuning mode.
▲/▼/◄/► buttons: in the menu press these buttons to navigate.
4. TFT display
5. MODE button: Press it to select the RADIO, DISC (if there is a disc in unit), SD (if there is a SD card in
unit), AUX IN mode.
6. IR sensor
