16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
While listening to any source...
1 Press the volume knob to enter [
FUNCTION
].
2 Turn the volume knob to select [
AUDIO CONTROL
], then press the
knob.
3 Turn the volume knob to make a selection (see the following table),
then press the knob.
4 Repeat step 3 until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press
.
Default:
XX
SUB-W LEVEL –15
to
+15
(
0
) Adjusts the subwoofer output level.
BAND1 LEVEL –8
to
+8
(
+6
)
The sound elements (frequency level, tone level, Q
factor) are preset into each selection (
BAND1 LEVEL
to
BAND5 LEVEL
).
Adjusts the level to memorize for each source.
(Before making an adjustment, select the source you
want to adjust.)
BAND2 LEVEL –8
to
+8
(
+6
)
BAND3 LEVEL –8
to
+8
(
+7
)
BAND4 LEVEL –8
to
+8
(
+3
)
BAND5 LEVEL –8
to
+8
(
0
)
PRESET EQ DRIVE EQ
/
TOP40
/
POWERFUL
/
ROCK
/
POPS
/
EASY
/
JAZZ
/
NATURAL
/
USER
:Selects a preset equalizer suitable to the music genre. (Select
[
USER
] to use the customized settings.)
[
DRIVE EQ
] is a preset equalizer that reduces noise outside the car or
running noise of the tyres.
BASS BOOST LEVEL1
/
LEVEL2
/
LEVEL3
:Selects your preferred bass boost level.;
OFF
:Cancels.
LOUDNESS LEVEL1
/
LEVEL2
:Selects your preferred low and high frequencies boost to
produce a well-balanced sound at a low volume level.;
OFF
:Cancels.
EXTRA EQ LEVEL1
/
LEVEL2
/
LEVEL3
:Selects your preferred elevation level to
enhance the sound in [
PRESET EQ
].;
OFF
:Cancels.
SUBWOOFER SET ON
:Turns on the subwoofer output.;
OFF
:Cancels.
LPF SUBWOOFER THROUGH
:All signals are sent to the subwoofer.;
85HZ
/
120HZ
/
160HZ
:Audio signals with frequencies lower than 85Hz/ 120Hz/
160Hz are sent to the subwoofer.
SUB-W PHASE REVERSE
(180°)/
NORMAL
(0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum
performance. (Selectable only if a setting other than [
THROUGH
] is
selected for [
LPF SUBWOOFER
].)
HPF THROUGH
:All signals are sent to the speakers.;
100HZ
/
120HZ
/
150HZ
:Audio signals with frequencies higher than 100Hz/ 120Hz/
150Hz are sent to the speakers.
FADER R15
to
F15
(
0
):Adjusts the rear and front speaker output balance.
BALANCE L15
to
R15
(
0
):Adjusts the left and right speaker output balance.
VOLUME OFFSET
For AUX:
–8
to
+8
(
0
) ; For other sources:
–8
to
0
:Presets the
volume adjustment level of each source. (Before adjustment, select
the source you want to adjust.)
SOUND RECNSTR
(Sound reconstruction)
ON
:Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are
lost in audio data compression.;
OFF
:Cancels.
[
SUB-W LEVEL
]/ [
LPF SUBWOOFER
]/ [
SUB-W PHASE
] is selectable only if
[
SUBWOOFER SET
] is set to [
ON
].
JS_KWD_KDC_BT45U_EN_EN_4.indd 16JS_KWD_KDC_BT45U_EN_EN_4.indd 16 27/8/2014 2:14:41 PM27/8/2014 2:14:41 PM
