1.LCD Screen
Channel Number. Changes from 1 to
8 as selected by the user.
Displays when battery level goes low.
Displays when Scan function is activated
D
isplayed when Key Lock function is activated
Displayed when transmitting a signal.
Displayed when receiving a signal.
Displayed the full volume level
USER GUIDE
SENCOR SMR 130
Personal Mobile Radio
Antenna
PTT(push to talk)
button
-press and hold
to transmit.
(Power)button
-press and hold to
turn the PMR
unit ON or OFF.
(UP)/(DOWN)buttons
-press to change
channels, volume, and
to select settings
during programming.
MENU button
-press to program
the PMR settings.
LCD screen
-Displays the current
Channel selection and
other radio symbols.
CALL button
-press to send a ringing
tone to other PMR units.
MIC(microphone)
Speaker
2. Installation
2.1 Removing the Belt clip
a. Pull the belt clip latch
away from the PMR.
b. While pulling the belt
clip latch, push up
the belt clip as
shown in Fig. 1.
2.2 Installing the Belt clip
a. Slide the belt clip into
the slot as shown in
Fig. 2.
b. A “click” indicates the
belt clip is locked into
its position.
2.3 Installing the Batteries
a. Slide down the battery compartment cover.
b. Insert the 3xAAA batteries. Position the
batteries according to the polarity marking
on the battery compartment. See Fig.3
c. Replace the battery cover. See Fig. 4.
Notes:
·Use only same type and make of batteries on the PMR units.
·The PMR units have a built-in Power Saver (PS) for maximum
battery life, but when not in use, turn the units OFF to save
battery power
·Remove the batteries if the units will not be used for a long period
of time.
Figure 1
Figure 2
Figure 3
Figure 4
