Download Program
This menu item is used to select the channel from
which to retrieve the correct time from the
Teletext. When this item is selected the television
set tunes to the selected program.
Time Offset
This menu item is used to set the offset needed to
adjust the time received from the Teletext channel
to represent the current time in the current
location.
• Brightness
The brightness control contains 63 discrete values
from the minimum to maximum setting.
• Colour
The colour control contains 63 discrete values
from the minimum to maximum setting.
• Contrast
The contrast control contains 63 discrete values
from the minimum to maximum setting.
• Sharpness
The sharpness control contains 63 discrete values
from the minimum to maximum setting.
• Forced mono (for stereo televisions only)
This command is used to activate or deactivate
the stereo feature in stereo sets. Toggle YES, NO
using the right/left cursor.
• Balance (for stereo televisions only)
To balance the output sound from TELEVISION’s
speakers left and right
• Treble (for stereo televisions only)
To set the treble frequencies of sound output from
TELEVISION’s speakers.
• Bass (for stereo televisions only)
To set the bass frequencies of sound output from
television’s speakers.
• AVL (Automatic Volume Leveller)
The Automatic Volume Leveller feature is shown
as “AVL” in the menu and its valid states are
“YES”; “NO”.
• Volume Fixed
The valid toggle states are "YES" and "NO": if
YES, the volume is fixed at a certain volume, if
NO, the volume contains 63 discrete values.
• Volume Bar
To display volume bar when adjusting volume,
select "YES". Select “NO” to hide the bar.
• Min Volume
This item sets the limit for minimum volume
allowed for the television set. Use right/left cursor
to adjust.
• Max Volume
This item sets the limit for the maximum volume
allowed for the television set. Use right/left cursor
to adjust.
• Switch on Volume
This item sets the television’s volume at switch
on. Use the right/left cursor to adjust.
• Buzzer Volume
This item sets the volume of the alarm buzzer.
Use the right/left cursor to adjust.
• Switch On Program
This item sets the television’s program at switch
on
• Power On
The Power On menu function defines the
behaviour of the television whenever AC Power is
applied.
The valid states are "FORCED", "STANDARD"
and “STANDBY”.
When “FORCED”, the television can only be
switched OFF by means of the main switch or a
set-up remote control or by ESP function (Energy
Saving Programmability controls the maximum
continuous viewing time allowed by the control
system).
When “STANDARD”, the television switches on
the previous status, ON or Stand-by.
When “STAND-BY”, the television always
switches on in Stand-by.
• Step Tuning (YES/NO)
If YES, TV programs (1 to 9) are tuned immedi-
ately when a digit is pressed.
If NO, tuning is performed only after the dash
disappears.
• Digit Time-out
This is the time-out to enter the second digit for
TV program 10 onwards.
