Operation
11
11
Operation
parameters.
• Horizontal Position: adjust horizontal
position of the image.
• Vertical Position: adjust vertical position
of the image.
• Clock: adjust the image frequency
manually.
• Phase: adjust the phase manually.
USB operation
General playback information
• Insert a USB drive into the USB port.
Select Media source and press ENTER button.
The screen will show a USB playback window,
in which you can select Music, Photo, Movie
and Text contents to play by pressing LEFT/
RIGHT cursor buttons and ENTER button.
• USB file systems supported: FAT16,
FAT32, 2.0 USB version is supported; maximum
capacity 1 TB. For correct and satisfactory
operation, licensed USB devices of well-known
brands should be used. Avoid using USB
devices of unknown brands. Playback of some
file formats cannot be supported.
• This unit supports playback of video files
with ASF, AVI, MKV, MPG extension, with
video codecs WMV9, DIVX, H263, MPEG-4,
MPEGII, XVID and audio codecs WMA, MP3,
DD(AC3).
The above list of extensions and codecs
is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.
• Some AVI files cannot be played due to
their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.
According to the USB 1.1/2.0 Standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.
Warning: usage of external USB drives
containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.
Operations of file playback
• Press cursor buttons to select Return
option and press ENTER button if you want to
go back to the previous menu.
• In the content menu, press cursor buttons
to select folder, press ENTER button or
button to enter it, then press cursor buttons to
select the file you want to watch or to listen to.
When highlighting the file, the file information
will appear on the right (not available for text
files) and picture will be previewed in the center
(not available for music and text files). Press
ENTER button or button to play the selected
file.
• While playback, press ENTER button; the
bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons or perform this operation
by pressing ENTER button. The operations are
as follows:
Play or pause playback All files
Select previous file All files
Select next file All files
Stop plabyack and return to
previous menu
All files
Select repeat playback
mode
All files
Play music in background
mode when photo or text
file is being browsed (you
should select music file first)
and
Text
