LG CT-29Q10ET [38/40] Audi o vi de

LG CT-29Q10ET [38/40] Audi o vi de

Connection

of

external

equipment

You

can

connect

additional

equipment,

such

as

VCRs,

camcorders

etc.

to

your

set.

Here

shown

may

be

somewhat

different

from

your

set.

Aerial

socket

1.

Connect

the

RF

out

socket

of

the

VCR

to

the

aerial

socket

on

the

back

of

the

set.

2.

Connect

the

aerial

cable

to

the

RF

aerial

in

socket

of

the

VCR.

3.Store

the

VCR

channel

on

a

desired

programme

number

using

the

'Manual

programme

tuning'section.

4.

Select

the

programme

number

where

the

VCR

channel

is

stored.

5.Press

the

PLAYbutton

on

the

VCR.

Audio

/

Video

in

/

out

sockets

(option)

1.

Connect

the

audio/video

out

sockets

of

the

VCR

to

audio/video

in

sockets

of

the

set

and

in

sockets

of

the

VCR

to

out

sockets

of

the

set.

2.

If

the

VCR

is

connected

to

the

AV

sockets

on

the

set,

press

the

TV/AVbutton

to

select

AV

1,

AV

2or

AV

3.

You

should

select

AV1,AV2orAV3,ifAV1,AV2orAV3socketsontheset

are

connected

to

the

VCR.

Note

:

AV1

outputs

signal

of

TV

programmed

channel

and

AV2

outputs

signal

of

current

monitoring

channel.

3.

Press

the

PLAYbutton

on

the

VCR.

The

VCR

playback


appears

on

the

screen.

You

can

also

record

programmes

received

by

the

TV

on

video

tape

via

audio/video

out

sockets.

Euro

scart

socket

(option)

1.

Connect

the

Euro

scart

socket

of

the

VCR

to

the

Euro

scart

socket

of

the

set.

2.

Press

the

PLAYbutton

on

the

VCR.

If

your

VCR

outputs

a

switching

voltage

the

set

will

switch

to

AV1

mode

automatically.

Otherwise

press

the

TV/AVbutton

on

the

remote

control

hand-

set

to

select

AV

1.

The

VCR

playback


appears

on

the

screen.

You

can

also

record

programmes

received

by

the

TV

on

video

tape.

Note

:

Signal

type

RGB,

i.e.

the

signals

red,

green

and

blue

can

only

be

selected

for

the

Euro

scart

socket.

These

signals

are

trans-

mitted,

for

example,

by

a

computer,

pay

TV

decoder,

game

machine

or


CD

unit,

etc.

AV2

ANT

IN

75Ω

LL

OUT

IN

VIDEO

(L/MONO)-AUDIO-(R)

VCR

AV2

OUT

IN

VIDEO

(LMONO)-AUDIO-(R)

OUT

IN

VIDEO

(L/MONO)-AUDIO-(R)

VCR

ANT

IN

75Ω

LL

AV1

AV2

OUT

IN

VDEO

(L/MONO)

AUDIO-(R)

VCR

ANT

IN

75Ω

LL

VCR

S-VIDEO VIDEO L/MONO

R

AUDIO

AV3

AV2

ANT

IN

75Ω

LL

OUT

IN

VIDEO(L/MONO)-AUDO(R)

VCR
