UD186 Engine Parts List

11. Fuel System

No.

CODE DESCRIPTION QTY/UNIT ORDER QTY PRICE MONEY REMARK

014020014200 Fuel filter cover 1

014020010500 Washer 4

014020014400 Pipe connection bolt 3

014020014500 Seal ring 1

014020014600 Bracket 1

014020014500 Seal ring 2

014020010500 Washer 1

014020014500 Seal ring 1

014020010500 Washer 1

014020015100 Spring 1

014020015200 Fuel filter body 1

014020010500 Washer 1

014020008300 Screw 1

014020015100 Spring 1

014020004000 Steel ball 1

014020015700 One way valve seat 1

014020010500 Washer 2

014020015900 Fuel retun pipe 1

014020014400 Pipe connection bolt 1

014020016100 Fuel tank 1

014020016200 Fuel tank cap 1

014020016300 Filling screen 1

014020016400 Primary fuel filter 1

014020010500 Packing 1

014020016600 Fuel outlet pipe 1

014020016700 Fuel cock seat 1

27 014020010500 Washer 3

28 511010616001 Hexagon bolt M6x16 3

29 014020016900 Fuel cock 1

30 014020017000 Pipe sleeve 1

31 014020017100 Fuel feed 1

32 014020017200 Fuel pipe 1

33 014020017300 High pressure fuel pipe and it's accessories 1

34 014020017400 Pipe clip 1
